Fortinet FortiAP 431F 2402 Mbit/s Grey, White Power over Ethernet (PoE)

These enterprise class 802.11ax indoor APs provide three radios. These top-of-theline access points provide OFDMA, a 2.5 Gigabit Ethernet port, plus an additional 1 Gbps Ethernet port for PoE diversity. The APs can provide 24/7 scanning across both bands while still providing access on both the 2.4 GHz and 5 GHz bands. The integrated BLE radio can be used for beacons and locationing applications.

ON ORDER

SKU: FAP-431F-E

Manufacturer: Fortinet

RRP Price €671.81

Specifications

Features

2.4 GHz
Yes
5 GHz
Yes
Maximum data transfer rate
2402 Mbit/s
Maximum data transfer rate (2.4 GHz)
1147 Mbit/s
Maximum data transfer rate (5 GHz)
2402 Mbit/s
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Frequency band
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11j, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.11w, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz
Bluetooth
Yes
MIMO
Yes
MIMO type
Multi User MIMO
Modulation
64-QAM, 128-QAM

Security

Security algorithms
EAP-AKA, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, MSCHAPv2, PEAP
Number of SSID supported
16
Wireless Intrusion Detection System (WIDS)
Yes

Management features

Web-based management
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
2
USB 2.0 ports quantity
1
USB connector type
USB Type-A
RS-232 interface
Yes

Power

Power over Ethernet (PoE)
Yes
Power consumption (max)
24.5 W

Design

Placement
Ceiling, Wall
Product colour
Grey, White
Cable lock slot
Yes
Cable lock slot type
Kensington
Reset button
Yes
LED indicators
Yes

Antenna

Antenna type
Internal
Antennas quantity
5
Antenna gain level (max)
5 dBi

Certificates

Certification
FCC, IC, CE, Japan, Korea, Taiwan, RoHS

Weight & dimensions

Width
210 mm
Depth
210 mm
Height
56.5 mm
Weight
980 g

Packaging data

Package weight
1.8 kg

Packaging content

Quantity per pack
1 pc(s)
Mounting kit
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 90%
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-35 - 70 °C

Accessories

License
