Fortinet 5 x GE RJ45 ports (including , 1 x WAN Port, 4 x Internal Ports)

The FortiGate/FortiWiFi 40F series provides a fast and secure SD-WAN solution in a compact fanless desktop form factor for enterprise branch offices and mid-sized businesses. Protects against cyber threats with system-on-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution. Fortinet’s Security-Driven Networking approach provides tight integration of the network to the new generation of security.

ON ORDER

SKU: FG-40F

Manufacturer: Fortinet Fortinet

RRP Price €426.34

Specifications

Data transmission

Firewall throughput
7.5 Mpps
Firewall throughput
5 Gbit/s
IPSec VPN throughput
4.4 Gbit/s
IPS/IDS throughput
1000 Mbit/s
SSL inspection throughput
310 Mbit/s
Firewall latency
4 µs
Security policies (max)
5000

Performance

Heat dissipation
52.55 BTU/h
Reset button
Yes
Noise level
0 dB

Network

VPN tunnels quantity
250
Active TCP connections (max)
700000

Security

Domains quantity
10

Management features

LED indicators
Yes

Ports & interfaces

Connectivity technology
Wired
USB 2.0 ports quantity
1
Ethernet LAN (RJ-45) ports
4
Ethernet LAN data rates
10,100,1000 Mbit/s
Console port
RJ-45
Number of console ports
1
WAN connection
Ethernet (RJ-45)

Design

Form factor
Desktop

Power

AC input voltage
100-240 V
AC input frequency
50 - 60 Hz
Input current
3 A
Power consumption (typical)
12.4 W
Power consumption (max)
15.4 W

Certificates

Certification
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB, ICSA Labs

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-35 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Operating altitude
0 - 2250 m

Weight & dimensions

Width
216 mm
Depth
160 mm
Height
38.5 mm
Weight
1 kg

Other features

Firewall throughput
5000 Mbit/s

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
