Fortinet FortiSwitch 108F-POE Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White

Security, Performance, and Manageability
The FortiSwitchâ„¢ Secure Access Family delivers outstanding
security, performance, and manageability. Secure, simple,
and scalable, FortiSwitch is the right choice for threatconscious businesses of all sizes.
Tightly integrated into the Fortinet Security Fabric via FortiLink,
FortiSwitch can be managed directly from the familiar
FortiGate interface. This single-pane-of-glass management
provides complete visibility and control of users and devices
on the network regardless of how they connect. This makes
the FortiSwitch ideal for SD-Branch and campus deployments
with applications that range from desktop to data center
aggregation, enabling businesses to converge their security
and network access.

Security Fabric Integration through FortiLink
FortiLink is an innovative proprietary management protocol that allows
our FortiGate Next-Generation Firewall to seamlessly manage any
FortiSwitch. FortiLink enables the FortiSwitch to become a logical
extension of the FortiGate, integrating it directly into the Fortinet Security Fabric.
This management option reduces complexity and decreases management costs
as network security and access layer functions are enabled and managed through
a single console. FortiLink integration enables centralized policy management,
including role-based access and control, making it easy to implement and manage.

ON ORDER

SKU: FS-108F-POE

Manufacturer: Fortinet Fortinet

RRP Price €532.37

Specifications

Management features

Switch type
Managed
Switch layer
L2+
Web-based management
Yes
Configuring Location Settings (CLI)
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity
2
Console port
RJ-45

Network

Networking standards
IEEE 802.3af, IEEE 802.3at
Link aggregation
Yes
Spanning tree protocol
Yes
Number of VLANs
4000

Data transmission

Switching capacity
20 Gbit/s
MAC address table
8000 entries
Latency (1 Gbps)
4 µs
Packet buffer memory
0.512 MB

Security

Access Control List (ACL)
Yes
Security algorithms
HTTPS, SNMP, SNMPv2, SNMPv3, SSH

Design

Rack mounting
Yes
Product colour
White
LED indicators
Yes

Performance

Memory type
DDR3-SDRAM
Internal memory
256 MB
Flash memory
32 MB
Telnet
Yes
Fanless
Yes

Power

Power source
AC
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
74.4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) power per port
65 W

Operational conditions

Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Storage relative humidity (H-H)
5 - 95%
Heat dissipation
34.12 BTU/h

Weight & dimensions

Width
250 mm
Depth
209 mm
Height
44 mm
Weight
1.7 kg

Certificates

Certification
FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Accessories

License
