Cisco Meraki MS355-24X Managed L3 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Silver

Cloud-Managed Switching for Performance-Driven Networks

Switch ports/stacking ports
- 8 × mGig ports
- 16 × 1G ports
- 2 × 40G or 4 × 10G fiber uplinks
- Stack up to 8 units
- QSFP28 stacking ports

Power/PoE
- All models include 740W
- Up to 30W per 1G port
- Up to 60W per mGig port
- Modular power supply/fans

Hardware platform
- Reliable platform with 24/7 Meraki Support
- 1RU rack mountable
- Voice and video QoS
- Non-blocking switch fabric

Cloud management
- Email alerts for switch management
- Remote troubleshooting tools
- Manage ports from a GUI-based dashboard
- Zero-touch provisioning
- Per-port and per-client usage statistics
- Secure, user-scheduled firmware updates

Switching capabilities
- Layer 3
- Warm spare redundancy (VRRP)
- OSPF Routing
- MAC forwarding entries, up to 32K
- DHCP Server, DHCP Relay
- 802.1X Authentication
- DHCP Snooping
- STP Enhancements
- IPv4 and IPv6 ACLs

END OF SALE
Successor: C9300X-24HX-M

SKU: MS355-24X-HW

Manufacturer: Cisco Cisco

RRP Price €7,855.75

Specifications

Management features

Switch type
Managed
Switch layer
L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
Packet redirection
Yes
System event log
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity
16
SFP+ module slots quantity
4
QSFP+ module slots quantity
2

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x
Port mirroring
Yes
Full duplex
Yes
Policy-based routing
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Virtual LAN features
Multicast VLAN, Stacked VLAN, Voice VLAN
Number of VLANs
4094

Data transmission

Switching capacity
352 Gbit/s
Forwarding rate
262 Mpps
MAC address table
32000 entries
Number of queues
8
Static route
Yes
Jumbo frames support
Yes
Jumbo frames
9600
Packet forwarding
Yes

Security

DHCP features
DHCP snooping, DHCP relay
Access Control List (ACL)
Yes
IGMP snooping
Yes
Loop protection
Yes
BPDU filtering/protection
Yes
Authentication
MAC-based authentication, Port-based authentication, Web-based authentication
Root protection
Yes
BPDU tunneling
Yes
Password protection
Yes
ARP attack prevention
Yes
Persistent MAC Learning (Sticky MAC)
Yes
Authentication type
RADIUS
Whitelist
Yes
Neighbor discovery snooping
Yes

Multicast features

Multicast support
Yes

Protocols

Switching protocols
DSCP-to-CoS, RSTP, STP, CDP, LLDP
Routing protocols
CDP
IPv4 & IPv6 features
Dual stack IPv4/IPv6

Design

Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Silver
Number of fans
3 fan(s)

Power

Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
47/63 Hz
Power consumption (typical)
740 W
Power consumption (max)
1744 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Operational conditions

Operating temperature (T-T)
0 - 45 °C
Operating relative humidity (H-H)
5 - 95%

Weight & dimensions

Width
484.6 mm
Depth
516.6 mm
Height
43.7 mm
Weight
5.58 kg

Packaging content

Cables included
AC, LAN (RJ-45)
User guide
Yes
Manual
Yes

Packaging data

Package type
Box

Certificates

Certification
CSA-US, FCC, IC, CE, RCM, RoHS

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
