Cisco Small Business SG350-28SFP Managed Switch | 24 Gigabit Ethernet SFP Slots | 2 SFP Slots | 2 Gigabit Ethernet Combo | Limited Lifetime Protection (SG350-28SFP-K9-UK)

The Cisco SG350-28SFP Switch is a next-generation managed switch that offers excellent performance, rich features, and ease of use.

With support for Layer 2 and 3 features, advanced security, routing, and energy-saving technology, it delivers a solid foundation for business applications today and in the future.

ON ORDER

SKU: SG350-28SFP-K9-UK

Manufacturer: Cisco Cisco

RRP Price €2,119.77

Specifications

Management features

Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
System event log
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity
2
SFP module slots quantity
26
Fiber optic connector
SFP
USB 2.0 ports quantity
1

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
No
Cable types supported
Cat5, Cat6, Cat7
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Head-of-line (HOL) blocking
Yes
Active link detection
Yes
Cable length detection
Yes
VLAN support
Yes
Virtual LAN features
Multicast VLAN, Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs
4094

Data transmission

Switching capacity
56 Gbit/s
Forwarding rate
41.66 Mpps
MAC address table
16384 entries
Number of queues
8
Static route
Yes
Number of static routes
1024
Number of IP interfaces
128
Jumbo frames support
Yes
Jumbo frames
9216
Packet buffer memory
1.5 MB

Security

DHCP features
DHCP server, DHCP snooping, DHCP relay, DHCP client
Access Control List (ACL)
Yes
Access Control List (ACL) rules
512
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, HTTPS, MD5, SSH, SSL/TLS
MAC address filtering
Yes
Static port security
Yes
SSH/SSL support
Yes
Loop protection
Yes
BPDU filtering/protection
Yes
IP-MAC-Port binding
Yes
Authentication
Guest VLAN, Port-based authentication, Web-based authentication
Root protection
Yes
DoS attack prevention
Yes
Authentication type
IEEE 802.1x, RADIUS
Queue scheduling algorithms
WRR+SP

Multicast features

Multicast support
Yes

Protocols

Management protocols
SNMP v1,2,3
GARP VLAN Registration Protocol (GVRP)
Yes
Intra-Site Automatic Tunnel Addressing Protocol (ISATAP)
Yes
IPv4 & IPv6 features
IPv6 ping, IPv6 tracert, IPv6 Telnet, Dual stack IPv4/IPv6

Design

Rack mounting
Yes
Form factor
1U
Product colour
Black
Reset button
Yes
LED indicators
Yes
Number of fans
1 fan(s)

Performance

Built-in processor
Yes
Internal memory
512 MB
Flash memory
256 MB
Noise level
43.6 dB
Firmware upgradeable
Yes
Telnet
Yes
Mean time between failures (MTBF)
101523 h

Power

Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50 Hz
Power consumption (max)
34.3 W
Power plug type
Type C

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Other features

Packaging content
Cisco SG350-28SFP Switch, Power Cord, Rack-Mount kit, Rubber feet, DB-9 to RJ45 Serial Cable, Quick Start guide, Pointer card with China RoHS, Technical support contacts, EU Directives 1999/5/EC Compliance Information

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Heat dissipation
117 BTU/h

Weight & dimensions

Width
202.5 mm
Depth
440 mm
Height
44.5 mm
Weight
2.7 kg

Packaging content

Cables included
AC
Quick start guide
Yes
Rack mount kit
Yes

Packaging data

Included power plug types
UK
Package width
297.2 mm
Package depth
544.8 mm
Package height
94.1 mm
Package weight
4.1 kg

Technical details

Products per shipping (inner) case
1 pc(s)

Certificates

Certification
UL, CSA, CE, FCC

Logistics data

Quantity per pack
1 pc(s)
Country of origin
China
Products per master (outer) case
1 pc(s)

Accessories

License
