Extreme networks X440-G2-12P-10GE4 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Burgundy

The ExtremeSwitching X440-G2 series is a scalable cost-effective family of edge switches powered by Extreme Networks ExtremeXOS, a highly resilient OS providing continuous uptime, manageability and operational efficiency. The X440-G2 series switches provide high-performance routing and switching, flexible stacking, PoE-plus support and comprehensive security, while extending the benefits of ExtremeXOS to the campus edge.

The X440-G2 Series easy-to-use, yet powerful, management services include role-based policies for controlled access to specific network applications. Select X440-G2 Series switches can also be cloud managed via ExtremeCloud, Extreme Networks innovative single-pane subscription-based management solution.

ON ORDER

SKU: 16531

Manufacturer: Extreme networks Extreme networks

RRP Price €2,783.74

Specifications

Management features

Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
12
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
4
Console port
RJ-45
Power connector
DC-in jack

Network

Networking standards
IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Full duplex
No
Flow control support
Yes
Link aggregation
Yes
VLAN support
Yes
Number of VLANs
4092

Data transmission

Switching capacity
104 Gbit/s
Forwarding rate
77.4 Mpps
MAC address table
16000 entries
Jumbo frames support
Yes

Design

Rack mounting
Yes
Product colour
Burgundy
LED indicators
Yes
Wall mountable
Yes

Performance

Built-in processor
Yes
Processor frequency
1000 MHz
Memory type
DDR3-SDRAM
Internal memory
1024 MB
Flash memory
4096 MB

Power

AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
264 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
12

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
0 - 60 °C

Weight & dimensions

Width
305 mm
Depth
261 mm
Height
44 mm
Weight
3.02 kg

Logistics data

Harmonized System (HS) code
85176990
