Eaton 9SX6KiRT uninterruptible power supply (UPS) 6 kVA 5400 W 11 AC outlet(s)

The Eaton 9SX UPS offers high availability, flexibility and advanced protection for infrastructure, industrial, medical, IT, networking, storage and telecom. Delivering on-line double conversion protection in versatile Rack/Tower format with up to 95% efficiency.

ON ORDER

SKU: 9SX6KIRT

Manufacturer: Eaton Eaton

RRP Price €4,189.66

Specifications

Features

Output power capacity
6 kVA
Output power
5400 W
Input operation voltage (min)
100 V
Input operation voltage (max)
276 V
Input frequency
40/70 Hz
Output operation voltage (min)
200 V
Output operation voltage (max)
240 V
Output voltage regulation
1%
Maximum current
90 A
Efficiency
98%
Crest factor
3:1
Output voltage Total Harmonic Distortion (THD)
2%
Input current Total Harmonic Distortion (THD)
5%
Noise level
45 dB

Ports & interfaces

AC outlet types
C13 coupler, C19 coupler, Terminal
Power plug
Terminal
AC outlets quantity
11 AC outlet(s)
USB 2.0 ports quantity
1
RS-232 ports
1

Battery

Typical backup time at half load
11 min
Automatic battery test
Yes

Design

Form factor
Rackmount/Tower
Rack capacity
3U
Product colour
Black
Display type
LCD

Operational conditions

Operating temperature (T-T)
0 - 40 °C

Safety regulation & standards

Safety
EN 62040-1, UL 1778, CSA 22.2

Sustainability

Sustainability certificates
ENERGY STAR

Weight & dimensions

Width
130 mm
Depth
685 mm
Height
440 mm
Weight
48 kg
