Cisco Aironet Dual-Band Directional Wi-Fi Patch Antenna, 6 dBi (2.4 GHz)/6 dBi (5 GHz), MIMO (4 Ports), Wall Mount, 4 RP-TNC Male Connectors, 1-Year Limited Hardware Warranty (AIR-ANT2566D4M-RS=)

The Cisco Aironet AIR-ANT2566D4M-RS= Dual-Band Directional Wi-Fi Patch Antenna is designed with improved performance in mind. It directs the energy it receives from the transmitter to provide more energy in one direction and less in other directions. This FCC-approved patch antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.

ON ORDER

SKU: AIR-ANT2566D4M-RS=

Manufacturer: Cisco Cisco

RRP Price €1,743.25

Specifications

Performance

Frequency band
2.4/5 GHz
Gain
6 dBi
Antenna gain (2.4 GHz)
6 dBi
Antenna gain (5 GHz)
6 dBi
Impedance
50 Ω
Antenna gain level (max)
6 dBi

Features

Antenna type
Directional antenna
Antenna connector type
RP-TNC
International Protection (IP) code
IP67

Operational conditions

Operating temperature (T-T)
-40 - 70 °C
Storage temperature (T-T)
-40 - 85 °C

Weight & dimensions

Width
254 mm
Depth
254 mm
Height
41 mm
Weight
1.13 kg

Packaging data

Package width
260.1 mm
Package depth
260.1 mm
Package height
215.9 mm
Package weight
1.25 kg

Packaging content

Quantity per pack
1 pc(s)

Logistics data

Country of origin
Malaysia

Accessories

License
