Cisco Aironet 3800p 5200 Mbit/s White Power over Ethernet (PoE)

For organizations paving the way for the new 802.11ac Wave 2 standard, the Cisco Aironet 3800 Series is the perfect solution. The access points go beyond getting ready for the new standard, providing the ultimate in flexibility and versatility.

For large enterprise organizations that rely on Wi-Fi to engage with customers, the 3800 Series is a hands-off product that’s intelligent enough to make decisions based on end-device activities and usage. This automation allows you to devote time to other pressing matters, secure in the knowledge that your Wi-Fi network is performing to its utmost potential.

The Aironet 3800 Series is packed with the features and capabilities that have made Cisco the industry leader, at a price point that is ideal for managing wireless growth, capacity, and coverage gaps in dense indoor environments.

ON ORDER

SKU: AIR-AP3802P-E-K9

Manufacturer: Cisco Cisco

RRP Price €3,241.87

Specifications

Features

2.4 GHz
Yes
5 GHz
Yes
Maximum data transfer rate
5200 Mbit/s
Ethernet LAN data rates
100,1000,2500,5000 Mbit/s
Frequency band
2.412 - 2.472, 5.18 - 5.32, 5.5 - 5.6, 5.64 - 5.7 GHz
Networking standards
IEEE 802.3bz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u
Channels quantity
29 channels
Channel bandwidth
160 MHz
Wi-Fi Multimedia (WMM)/(WME)
Yes

Security

Security algorithms
802.1x RADIUS, AES, EAP, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA, WPA2

Ports & interfaces

Ethernet LAN (RJ-45) ports
2

Power

Power over Ethernet (PoE)
Yes
Power supply
50 W

Design

Placement
Ceiling, Wall
Product colour
White
LED indicators
Yes
Internal
No

Antenna

Antenna type
External
Antenna features
Detachable antenna
Antenna gain level (max)
13 dBi
Number of connectors
4

Performance

Flash memory
256 MB
Internal memory
1024 MB

Certificates

Certification
UL 60950-1 CAN/CSA-C22.2 No. 60950-1 UL 2043 IEC 60950-1 EN 60950-1 EN 50155 FCC Part 15.107, 15.109, 15.247, 15.407, 14-30 RSS-247 (Canada) EN 300.328, EN 301.893 (Europe) ARIB-STD 66 (Japan) ARIB-STD T71 (Japan) EMI ICES-003 (Canada) VCCI (Japan) EN 301.489-1 / -17 (Europe) EN 60601-1-2 EMC

Weight & dimensions

Width
220 mm
Depth
220 mm
Height
67 mm
Weight
2.09 kg

Operational conditions

Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
-20 - 50 °C
Storage temperature (T-T)
-30 - 70 °C
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 4500 m

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
