Cisco ASR 1001-X wired router Grey

Cisco® ASR 1000 Series Aggregation Services Routers aggregate multiple WAN connections and network services including encryption and traffic management, and forward them across WAN connections at line speeds from 2.5 to 200 Gbps. The routers contain both hardware and software redundancy in an industry-leading high-availability design.

The latest additions to the Cisco ASR 1000 Series are the Cisco ASR 1002-HX Router and

the Cisco ASR 1001-HX Router. Both new routers support up to 100 Gbps in a 2-rack-unit (2RU) and 60 Gbps in a 1-rack-unit (1RU) form factor, respectively. The ASR 1002-HX has 8 built-in 10-Gigabit Ethernet (GE) ports and 8 1-GE ports, with the Ethernet port adapter (EPA) slot for expansion. The ASR 1001-HX has 4 built-in 10-GE ports, 8 1-GE ports, and 4 configurable 10-GE or 1-GE ports

The Cisco ASR 1000 Series supports Cisco IOS® XE Software, a modular operating system with modular packaging, feature velocity, and powerful resiliency. The Cisco ASR 1000 Series Embedded Services Processors (ESPs), which are based on Cisco Flow Processor™ technology, accelerate many advanced features such as crypto-based access security; Network Address Translation (NAT), thread defense with Cisco Zone-Based Firewall (ZBFW), deep packet inspection (DPI), Cisco Unified Border Element (CUBE), and a diverse set of data-center-interconnect (DCI) features. These services are implemented in Cisco IOS XE Software without the need for additional hardware support.

Cisco ASR 1000 Routers sit at the edge of your enterprise data center or large office connecting to the WAN, as well as in service provider points of presence (POPs). The Cisco ASR 1000 Series will benefit the following types of customers:

- Enterprises experiencing explosive network traffic as mobility, cloud networking, and video and collaboration usage increase: Cisco ASRs consolidate these various traffic streams and apply traffic management and redundancy properties to them to maintain consistent performance among enterprise sites and cloud locations.
- Network service providers needing to deliver high-performance services, such as DCI and branch-office server aggregation, to business customers: Service providers can also use the multiservice routers to deploy hosted and managed services to business and multimedia services to residential customers.
- Existing Cisco 7200 Series Router (end-of-sale) customers looking for simple migration to a new multiservice platform that delivers greater performance with the same design.

Features and Benefits
The Cisco ASR 1000 Series Routers carry a modular yet integrated design, so network operators can increase their network capacity and services without a hardware upgrade. With flexibility in the number of connections, speed maximums, and price, you don’t have to under- or overprovision for any network location.

Alternatively, you also have the option to buy “-X” and “-HX” models, so you can increase throughput by simply purchasing upgrade licenses as you grow to increase your network speed dynamically.

ON ORDER

SKU: ASR1001-X

Manufacturer: Cisco Cisco

RRP Price €38,527.31

Specifications

WAN connection

Ethernet WAN
Yes

Network

Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000,10000 Mbit/s

Management features

Web-based management
Yes
Quality of Service (QoS) support
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
6
Installed SFP modules quantity
2
DC-in jack
Yes

Security

Firewall
Yes

Features

Processor cores
4
Flash memory
1024 MB
Internal memory
8192 MB
Safety
UL60950-1, CSA C22.2, No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1

Design

Product colour
Grey
Rack mounting
Yes
Wall mountable
No
LED indicators
Yes
On/off switch
Yes

Power

Power consumption (typical)
250 W
Power source type
AC, DC
AC input voltage
85 - 264 V

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
152 - 3048 m

Weight & dimensions

Width
439.4 mm
Depth
461.5 mm
Height
43.4 mm
Weight
11.3 kg

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
