Crestron C2N-IO digital/analogue I/O module Analog Relay channel

The C2N-IO is a very compact device that adds control ports to any Crestron® 2-Series or 3-Series® control system. It connects via the Cresnet® control network and provides one RS-232, one IR, and two relay control ports.[1] It can be mounted to any flat surface using two screws or adhesive reclosable fastener (3M® Dual Lock® included).

The C2N-IO is ideally designed for use with a Crestron touch screen control system ( TPCS-4SM, TPCS-4SMD, or TSCW-730), providing an advanced wall mount control package that fits in a 2-gang US or UK electrical box. The C2N-IO can be mounted inside the electrical box behind the touch screen, or it can be installed remotely requiring just one Cresnet control cable for power and communications.

ON ORDER

SKU: C2N-IO

Manufacturer: Crestron Crestron

RRP Price €313.20

Specifications

Features

Module type
Analog
Signal direction
Input/output
Channel type
Relay channel

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
10 - 90 °C

Weight & dimensions

Width
89 mm
Depth
112 mm
Height
58 mm
Weight
75 g

Accessories

License
