D-Link 20km Long Range Wireless AC Bridge

The power to deliver connectivity over an even longer distance.

The DAP-3712 is the essential infrastructure wireless solution in providing high-speed connectivity to what was previously believed to be impossible-to-reach rural areas and challenging terrain.

High-Gain Directional Antenna
Fast, stable, and long-range wireless coverage for up to 20 km

TDMA Technology
High speeds and consistent coverage that filters out interference

IP66 Rated
Water-resistant and dust-tight housing boasts a longer product life

Point-to-Point and Point-to-Multipoint
Distribute connectivity to single or multiple locations wirelessly over long distances

8 kV Surge Protection
Your device and network are protected against unexpected surges, such as lightning

High-Speed Wi-Fi
Blazing speeds of up to 867 Mbps

Wi-Fi Security
128-bit personal and enterprise wireless encryption

PoE Ready
Power over Ethernet makes for an easier installation with a single cable

Designed for Wireless ISPs

Rapid and cost-effective Internet distribution to get customers connected

The power to withstand tough weather

The DAP-3712 is enclosed in an unobtrusive IP66-rated housing, protecting it from rain and dirt. With built-in 8 kV surge protection, the DAP-3712 has protection against unexpected surges (such as lightning strikes), enabling it to be deployed where it’s needed, even in harsh environments and tough conditions.

Bring connectivity to areas with limited or no access to fixed internet.

The DAP-3712 features state-of-the-art hardware, including powerful high-gain 23 dBi directional antennas that effortlessly extend the coverage of 5GHz wireless AC speeds of up to 867Mbps to distances of up to 20 km away.

Consistent coverage that filters out interference

The DAP-3712 supports TDMA technology, creating a schedule for the bridge's access point and the client. The sender and receiver are allocated a time slot for transmissions, eliminating hidden node data collisions, maximising airtime efficiency, significantly cutting down interference, and dramatically improving the transfer rate.

Simple installation with Power over Ethernet (PoE)

The DAP-3712 comes with a PoE injector included. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.

Free Next-Business-Day Service

Enjoy our free Next Business Day service, as standard with D-Link Business products, to replace faulty equipment quickly.

Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increases the lengths of warranties and further minimises downtime.

ON ORDER

SKU: DAP-3712

Manufacturer: D-Link D-Link

RRP Price €266.58

Specifications

Data transmission

Maximum data transfer rate
867 Mbit/s
Maximum transfer distance
20000 m

Antenna

Antenna design
External
Antenna gain level (max)
23 dBi
Antennas quantity
1

Wireless LAN features

Wi-Fi
Yes
Wi-Fi band
Single-band (5 GHz)
WLAN data transfer rate (max)
867 Mbit/s
Frequency band
5.180 - 5.825 GHz
Signal strength
27 dBm
Channels quantity
2 channels

Network

Ethernet LAN
Yes
Ethernet LAN interface type
Gigabit Ethernet
Ethernet LAN data rates
100,1000 Mbit/s
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Cabling technology
10/100/1000Base-T(X)
Static IP
Yes

Ports & interfaces

Connectivity technology
Wired & Wireless
Ethernet LAN (RJ-45) ports
1

Security

Security algorithms
128-bit AES
MAC address filtering
Yes

Management features

Web-based management
Yes
DHCP client
Yes

Features

Product type
Network bridge
Material
Acrylonitrile butadiene styrene (ABS)
Mounting type
Pole
Product colour
White
LED indicators
Signal strength
Automatic Transmit Power Control (ATPC)
Yes
Reset button
Yes
International Protection (IP) code
IP66
Surge protection
Yes

Power

Power source type
PoE
Power consumption (typical)
15 W
Power consumption (max)
15 W
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) voltage
48 V

Operational conditions

Operating temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
0 - 90%
Storage temperature (T-T)
-40 - 85 °C
Storage relative humidity (H-H)
0 - 90%

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC)
Certification
CE, FCC

Weight & dimensions

Width
372 mm
Depth
241 mm
Height
372 mm
Weight
900 g

Packaging data

Quantity per pack
1 pc(s)

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
