DS3608-XR3RF50AZVW

ON ORDER

SKU: DS3608-XR3RF50AZVW

Manufacturer: Zebra Zebra

RRP Price €1,060.59

Specifications

Scanning

Type
Handheld bar code reader
Scanner type
1D/2D
Sensor type
Laser
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Optical sensor resolution (W x H)
1280 x 800 pixels
Wavelength
520 nm
Tilt reading angle
-60 - 60°
Pitch reading angle
-60 - 60°
Yaw reading angle
-360 - 360°

Ports & interfaces

Connectivity technology
Wired
Standard interfaces
Keyboard wedge, RS-232, USB
Ethernet LAN
Yes

Performance

International Protection (IP) code
IP67
Protection features
Water resistant
LED indicators
Yes
Print contrast
25%
Product colour
Black, Green
Programming function
Yes

Power

Power source type
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
3100 mAh

Weight & dimensions

Width
132 mm
Depth
76 mm
Height
185 mm
Weight
308 g

Packaging data

External power adapter
Yes

Operational conditions

Operating temperature (T-T)
-30 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Drop resistance
2.4 m

Technical details

Compliance certificates
RoHS

Accessories

License
