DS3678-HP3U42A2SKW

ON ORDER

SKU: DS3678-HP3U42A2SKW

Manufacturer: Zebra Zebra

RRP Price €1,443.78

Specifications

Scanning

Type
Handheld bar code reader
Optical sensor resolution
1280 pixels
Scanner type
1D/2D
Sensor type
Laser
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Wavelength
655 nm
Tilt reading angle
-65 - 65°
Pitch reading angle
-65 - 65°
Yaw reading angle
-45 - 45°

Ports & interfaces

Connectivity technology
Wired & Wireless
Standard interfaces
RS-232, USB, Keyboard wedge
Wireless range
100 m
Bluetooth version
4.0
Bluetooth Low Energy (BLE)
Yes
Ethernet LAN
Yes

Performance

International Protection (IP) code
IP67
Protection features
Dust resistant, Shock resistant, Water resistant
LED indicators
Yes
Product colour
Black, Green
Programming function
Yes

Power

Power source type
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
3100 mAh
Number of reads per charge
100000

Weight & dimensions

Width
142 mm
Depth
76 mm
Height
185 mm
Weight
411 g

Operational conditions

Operating temperature (T-T)
-20 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%

Technical details

Compliance certificates
RoHS

Logistics data

Harmonized System (HS) code
84716070

Accessories

License

Related Products
