NETGEAR GS110MX Unmanaged 10G Ethernet (100/1000/10000) Black

Unlock the Potential of your 10G/Multi-Gig devices
The XS505M and XS508M come with copper Ethernet 5-speed ports that provide either FastEthernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity, as well as 1 SFP+ Fiber port with 1-Gigabit or 10-Gigabit connectivity.

Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS505M or XS508M give the exact speed required, no downgrade. Also, the new NETGEAR 5-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6 wiring, therefore reducing wiring costs and hassle

ON ORDER

SKU: GS110MX-100PES

Manufacturer: Netgear Netgear

RRP Price €403.20

Specifications

Management features

Switch type
Unmanaged
Quality of Service (QoS) support
Yes
MIB support
Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
10
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity
8
Power connector
DC-in jack

Network

Networking standards
IEEE 802.1p, IEEE 802.3x
10G support
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
VLAN support
Yes

Data transmission

Switching capacity
56 Gbit/s
MAC address table
16000 entries
Number of trunks
8
Static route
Yes
Jumbo frames support
Yes
Jumbo frames
10240

Security

IGMP snooping
Yes

Multicast features

Multicast support
Yes

Design

Rack mounting
Yes
Product colour
Black
LED indicators
Yes
Safety
UL 60950-1/CAN/CSA C22.2 No. 60960-1-07 EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013 AS/NZS 60950.1:2015

Power

Power source
DC
DC input voltage
13.2 V
Power consumption (typical)
4.8 W
Power consumption (max)
6.6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Heat dissipation
45.14 BTU/h

Weight & dimensions

Width
236 mm
Depth
102 mm
Height
27 mm
Weight
740 g

Certificates

Certification
47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN 55032:2012 +AC:2013, CISPR 32:2012, AS/NZS CISPR 32:2013, EN 55032:2015 +AC:2016, CISPR 32:2015 +COR1:2016, AS/NZS CISPR 32:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010 +A1:2015, AS/NZS CISPR 32:2015, VCCI-CISPR 32:2016,

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
