NETGEAR GS305PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

NETGEAR GS305PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Name: NETGEAR GS305PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Brand: Netgear
SKU: GS305PP-100PES
Price: 212.21 EUR
Availability: OutOfStock

Expanding Wired Connectivity for SOHO Networks

NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly. The GS305P/GS305PP and GS308P with Power-over-Ethernet (PoE) provides power and data from a single Ethernet (CAT-5) cable to devices such as IP cameras, VoIP/Internet-based phones, wireless access points, etc. Just step up to GS316, GS324 or GS348 directly to avoid congestion due to stacking up lower port count switches and be ready for future expansion.

ON ORDER

SKU: GS305PP-100PES

Manufacturer: Netgear Netgear

RRP Price €212.21

Specifications

Management features

Switch type

Unmanaged

Quality of Service (QoS) support

Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Gigabit Ethernet (copper) ports quantity

Power connector

DC-in jack

Network

Networking standards

IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

10G support

Copper ethernet cabling technology

10BASE-T, 100BASE-TX, 1000BASE-T

Full duplex

Yes

Auto MDI/MDI-X

Yes

Auto-sensing

Yes

Auto-negotiation

Yes

Cable length detection

Yes

Data transmission

Switching capacity

10 Gbit/s

Forwarding rate

1.448 Mpps

MAC address table

2000 entries

Latency (1 Gbps)

2.4 µs

Jumbo frames support

Yes

Jumbo frames

9216

Packet buffer memory

128 MB

Design

Rack mounting

Product colour

Black

Housing material

Metal

Reset button

Yes

LED indicators

Activity, Link, PoE, Power

Wall mountable

Yes

Performance

Mean time between failures (MTBF)

6710127 h

Power

DC input voltage

54 V

Input current

1.66 A

Power consumption (typical)

2.89 W

Power consumption (max)

88.89 W

Power over Ethernet (PoE)

Yes

Power over Ethernet plus (PoE+) ports quantity

Power over Ethernet (PoE) power per port

30 W

Total Power over Ethernet (PoE) budget

83 W

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 95%

Heat dissipation

304 BTU/h

Weight & dimensions

Width

158 mm

Depth

101 mm

Height

29 mm

Weight

410 g

Packaging content

Manual

Yes

Packaging data

Package width

269 mm

Package depth

73 mm

Package height

215 mm

Package weight

1.3 kg

Certificates

Certification

CE Mark, FCC Part 15 Class B, IC Class B, RCM, CCC, VCCI, CB, CE VD, CCC

Logistics data

Master (outer) case width

237 mm

Master (outer) case length

469 mm

Master (outer) case height

306 mm

Harmonized System (HS) code

85176990

Master (outer) case gross weight

8.52 kg

Products per master (outer) case

6 pc(s)

Description

Manufacturer

Netgear

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.41 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download

Accessories

No Accessories Found!

License

No License Found!
