Cisco IR1101 wired router Fast Ethernet Black

The modularity and expansion capabilities of the IR1101 Integrated Services Router Rugged can help extend product lifetime. Its compact, modular, ruggedized design is excellent for mission-critical cases. It offers stronger industrial router security and simplified management with SD-WAN architecture, edge compute, and IOS XE.

Modularity and investment protection
The IR1101 has a highly modular and expandable hardware designed to extend product lifetime. Internal and expansion modules give you the flexibility to add or upgrade WAN and storage components as technologies and your needs evolve.

A 5G-ready, dual WAN gigabit router
When provisioned with two cellular modules, the IR1101 enables concurrent connectivity to two cellular networks for WAN redundancy, enhanced data throughputs, load balancing, and differentiated services. The hardware is future-proofed to handle 5G.

Compact and ruggedized router. Low power consumption.
With its small form-factor (less than 2RU) and low typical power consumption of 10 W, the IR1101 is easy to install and integrate into space- and power-constrained cabinet installations.

Software-defined WAN on the IR1101
Now you can leverage IT expertise to a broad, distributed network, operate at scale, and lower total cost of ownership. Cisco SD-WAN architecture delivers scale, simplicity, and unified management for extending enterprise networks to a distributed IoT deployment.

Open extensible platform with IOS-XE at the edge
Cisco IOS XE is highly programmable, with open and standards-based APIs, and next-generation, multilayer security built in. This unified software stack is ideal for process and workflow automation, enabling you to qualify and deploy new services more quickly.

Self-healing utility grids to reduce outages
Remotely manage thousands of miles of unmanned power grids between distribution substations and the control center. Improve power flow, Volt-VAR optimization, and fault detection and isolation for reduced outage durations and cost.

Improve public safety and regulate traffic
The IR1101 provides redundant WAN connectivity for increased reliability. And with intelligence at the edge, you can accelerate decision making for mission-critical applications, such as public safety, regulating traffic flow, and detecting traffic violations.

Safeguard oil and gas pipelines
Get real-time decisions at the edge for faster response. Utilize cellular redundancy to manage thousands of miles of remote oil and gas pipelines to quickly identify and fix problems, limit downtime, and reduce costs.

Secure financial transactions
Extend your branch network to remotely manage ATM machines. Utilize SD-WAN architecture for simple, scalable deployment. Secure financial transactions with high-end multilayer security, and redundant, high-speed connectivity.

ON ORDER

SKU: IR1101-K9

Manufacturer: Cisco Cisco

RRP Price €1,710.74

Specifications

WAN connection

Ethernet WAN
Yes
DSL WAN
No

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q
Ethernet interface type
Fast Ethernet
Ethernet LAN
Yes
Cabling technology
10/100Base-T(X)
Ethernet LAN data rates
10,100 Mbit/s
Multicast support
Yes

Mobile network

Mobile network generation
Not supported

Management features

Quality of Service (QoS) support
Yes
Reset button
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
4
Combo SFP ports quantity
1
USB ports quantity
2
USB version
2.0
Serial ports quantity
1

Protocols

Routing protocols
BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols
IPv4, IPv6
DHCP client
Yes
DHCP server
Yes
Supported protocols
SCADA, DNP3, T101-104, Raw Socket TCP, UDP

Security

Security algorithms
256-bit AES, HTTPS, IPSec, SSL/TLS
Firewall
Yes
Firewall security
Cisco IOS
Authentication method
Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Access Control List (ACL)
Yes
Network address translation (NAT)
Yes
VPN support
Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN

Features

Storage media
Flash
Flash memory
8000 MB
Internal memory
4096 MB
Internal memory type
DRAM
Safety
UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Electromagnetic compatibility
47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014

Design

Product colour
Black
LED indicators
Yes

Power

Power consumption (typical)
9.8 W
Power source type
DC
Output voltage
12 - 48 V

Operational conditions

Operating temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
10 - 95%
Operating altitude
-152.4 - 1524 m

Weight & dimensions

Width
132.5 mm
Depth
124.9 mm
Height
60 mm
Weight
1.02 kg

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
