Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km

The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C’s original specifications and complies with MSA (Multi-Source Agreement) standards.

This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling.

The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.

ON ORDER

SKU: N286-01GLX-SLX

Manufacturer: Eaton Eaton

RRP Price €53.59

Specifications

Performance

SFP transceiver type
Fiber optic
Maximum data transfer rate
10000 Mbit/s
Interface type
SFP+
Single-mode fiber (SMF) supported
Yes
Fiber optic connector
LC
Fiber cable diameters supported (core/cladding)
9/125 µm
Maximum transfer distance
10000 m
Wavelength
1310 nm
Cabling technology
1000Base

Features

Product colour
Metallic
Easy to install
Yes

Certificates

Compliance certificates
RoHS

Operational conditions

Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
10 - 85%

Weight & dimensions

Width
13.2 mm
Depth
56.9 mm
Height
8.4 mm
Weight
20 g

Packaging content

Quantity per pack
1 pc(s)

Packaging data

Package width
114 mm
Package depth
45 mm
Package height
21.6 mm
Package weight
30 g

Logistics data

Master (outer) case GTIN (EAN/UPC)
10037332197433
Master (outer) case width
230.1 mm
Master (outer) case length
130 mm
Harmonized System (HS) code
8517.62.0090
Master (outer) case height
74.9 mm
Master (outer) case gross weight
430 g
Products per master (outer) case
10 pc(s)
Country of origin
China
