Tripp Lite N286I-1P25GLXD1 Industrial Gigabit SFP Transceiver - 1000Base-LX, Singlemode, LC Duplex, DDM, -40° to 85°C, 10 km (6.2 mi.)

Industrial-Grade SFP Transceiver Module Connects Fiber Cabling to Your Network Device
N286I-1P25GLXD1 provides 1000Base-LX throughput over singlemode fiber cable up to 10 kilometers (6.2 miles) at 1310 nm. It complies with IEEE 802.3z 1000Base-LX standards, supports Digital Diagnostic Monitoring (DDM) and transmits bi-directional data at speeds up to 1.25 Gbps. Connect the transceiver to any standard SFP slot on an industrial switch or fiber converter, such as NGI-Series Industrial Gigabit Ethernet Switches.

Built to Last in Harsh Industrial Environments
The N286I-1P25GLXD1 adds 10/100/1000 Mbps Gigabit Ethernet connectivity to your industrial application, such as factory automation, rail and intelligent transportation systems (ITSs), marine, oil and gas, mining and other environments with wide temperature ranges. The high-strength housing withstands vibration, shock and free fall. It can also operate in extreme temperatures ranging from -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit).

Hot-Pluggable for Installation Without Network Interruption
This transceiver module is fully hot-pluggable, so you can install it without a potentially costly network shutdown or device reboot. Just plug the SFP end of the transceiver into your network device. The other end has an LC duplex connector to link with high-speed fiber cable (sold separately). A convenient bail clasp latch helps you carefully remove the module from the device.

ON ORDER

SKU: N286I-1P25GLXD1

Manufacturer: Eaton Eaton

RRP Price €40.83

Specifications

Performance

SFP transceiver type
Fiber optic
Maximum data transfer rate
1000 Mbit/s
Interface type
SFP
Fiber optic connector
LC
SFP transceiver standard
LX
Maximum transfer distance
10000 m
Wavelength
1310 nm
Networking standards
IEEE 802.3z
Digital Diagnostics Monitoring (DDM)
Yes

Features

Product colour
Metallic
Brand compatibility
TRENDnet

Certificates

Compliance certificates
RoHS

Operational conditions

Minimum operating temperature
-40 °C
Maximum operating temperature
85 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%

Weight & dimensions

Width
14 mm
Depth
67.1 mm
Height
10.9 mm
Weight
10 g

Packaging content

Quantity per pack
1 pc(s)

Packaging data

Package width
105.9 mm
Package depth
51.1 mm
Package height
20.1 mm
Package weight
30 g

Logistics data

Master (outer) case GTIN (EAN/UPC)
10037332268331
Master (outer) case width
111 mm
Master (outer) case length
113 mm
Harmonized System (HS) code
8517.62.0090
Master (outer) case height
120.9 mm
Master (outer) case gross weight
390 g
Products per master (outer) case
10 pc(s)
Country of origin
Taiwan

Accessories

License

Related Products
