Tripp Lite N520-01M Duplex Multimode 50/125 Fiber Patch Cable (LC/LC), 1M (3 ft.)

Constructed with 50/125 micron cable
Length: 1-meter
Use on fiber and fibre channel installations
LC male to LC male connectors
Higher bandwidth optimized for gigabit and 10Gbps networks
Backward compatible with 62.5 micron fiber
Built-in headroom for future applications
Number of fibers: 2
Fiber type: All glass graded index
Core diameter: Two 50+/-3 microns
CLAD diameter: 125+/-2 microns
Primary coating diameter: 245+/-15 microns
Primary coating material: Acrylate
Secondary coating diameter: 900+/-50 microns
Secondary coating material: PVC
Attenuation @850NM: 3.5DB/KM maximum, @1300NM: 1.0DB/KM maximum
Bandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimum
Numerical aperture: .275 nominal
Proof test level: 100,000 PSI
Insertion loss testing performed on every connector (0.2db typical) and provided with cable
Beveled edge on ends of glass makes insertion of plug a breeze

ON ORDER

SKU: N520-01M

Manufacturer: Eaton Eaton

RRP Price €12.85

Specifications

Features

Cable length
1 m
Fibre optic type
OM2
Connector 1
LC
Connector 2
LC
Connector 1 gender
Male
Connector 2 gender
Male
Product colour
Orange
Full duplex
Yes
Core diameter
50 µm
Cladding diameter
125 µm
Fiber mode structure
Multi-mode
Wavelengths supported
850 nm
Data transfer rate
1 Gbit/s
Insertion loss
0.2 dB
Jacket material
Polyvinyl chloride (PVC)

Certificates

Compliance certificates
RoHS

Packaging data

Package width
177.8 mm
Package depth
12.7 mm
Package height
228.6 mm
Package weight
10 g

Other features

Core / cladding diameter
50/125 µm
Connector(s)
LC (x4)

Logistics data

Master (outer) case GTIN (EAN/UPC)
10037332119527
Country of origin
China
Master (outer) case width
203.2 mm
Harmonized System (HS) code
8544.70.0000
Master (outer) case length
254 mm
Master (outer) case height
63.5 mm
Master (outer) case gross weight
100 g
Products per master (outer) case
10 pc(s)
