Tripp Lite N520-20M Duplex Multimode 50/125 Fiber Patch Cable (LC/LC), 20M (65 ft.)

Name: Tripp Lite N520-20M Duplex Multimode 50/125 Fiber Patch Cable (LC/LC), 20M (65 ft.)
Brand: Eaton
SKU: N520-20M
Price: 33.19 EUR
Availability: OutOfStock

Constructed with 50/125 micron cable
Length - 20M
Use on fiber and fibre channel installations
LC male to LC male connectors
Higher bandwidth optimized for gigabit and 10Gbps networks
Backward compatible with 62.5 micron fiber
Built-in headroom for future applications
Number of fibers: 2
Fiber type: all glass graded index
Core diameter: Two 50+/-3 microns
CLAD diameter: 125+/-2 microns
Primary coating diameter: 245+/-15 microns
Primary coating material: acrylate
Secondary coating diameter: 900+/-50 microns
Secondary coating material: PVC
Attenuation @850NM: 3.5DB/KM maximum, @1300NM: 1.0DB/KM maximum
Bandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimum
Bandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimum
Proof test level: 100,000 PSI
Insertion loss testing performed on every connector (0.2db typical) and provided with cable
Beveled edge on ends of glass makes insertion of plug a breeze

ON ORDER

SKU: N520-20M

Manufacturer: Eaton Eaton

RRP Price €33.19

Specifications

Features

Cable length

20 m

Connector 1

Connector 2

Connector 1 gender

Male

Connector 2 gender

Male

Product colour

Orange

Full duplex

Yes

Weight & dimensions

Weight

140 g

Packaging data

Package width

152.4 mm

Package depth

167.6 mm

Package height

12.7 mm

Package weight

140 g

Logistics data

Master (outer) case GTIN (EAN/UPC)

10037332123616

Country of origin

China

Master (outer) case width

182.9 mm

Harmonized System (HS) code

8544.70.0000

Master (outer) case length

348 mm

Master (outer) case height

139.7 mm

Master (outer) case gross weight

1.59 kg

Products per master (outer) case

10 pc(s)

Other features

Core / cladding diameter

50/125 µm

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.14 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
