StarTech.com 1 Port RS232 Serial Ethernet Device Server - PoE Power Over Ethernet

Connect to, configure and remotely manage an RS-232 serial device over an IP network

The NETRS2321POE 1 Port RS232 Serial Ethernet Device Server - PoE (Power Over Ethernet) allows you to install your RS232 devices anywhere on your TCP/IP Ethernet WAN/LAN, and access them as if they were right beside you - even over the Internet!

The Serial Device Server is designed to function seamlessly with your other integrated and add-on serial ports as if they were right inside your computer. Perfect for industrial automation, security, Point of Sale, or any long-range serial application, delivering reliable performance in any environment.

The Ethernet/serial device server supports PoE (Power over Ethernet) when connected to a PoE compliant device - eliminating the need for an external power supply and outlet, and making it easier to situate the device server as needed.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- PoE support gives you the freedom to situate your serial device where it is needed even when no power outlet is available
- IP-based connection to your serial devices allows remote administration from anywhere; even over the Internet
- Remotely connect to multiple NETRS2321POE units with a single PC for simple and efficient management of devices from a single location

ON ORDER

SKU: NETRS2321POE

Manufacturer: StarTech.com StarTech.com

RRP Price €218.83

Specifications

Technical details

Serial ports quantity
1
Serial interface type
RS-232
Ethernet LAN data rates
10,100 Mbit/s
Data transfer rate
0.1152 Mbit/s
Networking standards
IEEE 802.3af
Baud rate
115.2 Kbit/s
Data bits
6, 7, 8
Stop bits
1, 2
Mean time between failures (MTBF)
233403 h
Compliance certificates
RoHS
Certification
CE, FCC, REACH, TAA

Ports & interfaces

Ethernet LAN (RJ-45) ports
1
Cabling technology
10/100Base-T(X)

Power

Input voltage
100 - 240 V
Output voltage
12 V
Output current
0.1 A
Power consumption
100 mA
Power plug type
Type M
Compatible power plug types
EU, UK, US
Input current
0.3 A

Protocols

Supported network protocols
UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping

Indication

LED indicators
Activity, Link
Link/Act LED
Yes

Software

Windows operating systems supported
Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional

Weight & dimensions

Weight
259 g
Dimensions (WxDxH)
66.3 x 107 x 25 mm
Package width
296 mm
Package length
19.2 cm
Package height
70 mm
Package weight
963 g

Operational conditions

Operating temperature (T-T)
0 - 55 °C
Storage temperature (T-T)
-20 - 85 °C
Operating relative humidity (H-H)
5 - 95%

Other features

Compatible operating systems
Windows Vista (32), XP (32), 2000

Packaging content

User guide
Yes

Accessories

License
