TELTONIKA OTD140 - OUTDOOR ROUTER IP55 4G LTE

Name: TELTONIKA OTD140 - OUTDOOR ROUTER IP55 4G LTE
Brand: Teltonika
SKU: OTD140
Price: 130.07 EUR
Availability: OutOfStock

ON ORDER

SKU: OTD140

Manufacturer: Teltonika

RRP Price €130.07

Specifications

WAN connection

Ethernet WAN

Yes

DSL WAN

SIM card slot

Yes

3G/4G USB modem compatibility

SFP WAN

Network

Networking standards

IEEE 802.3, IEEE 802.3az, IEEE 802.3u

Ethernet interface type

Gigabit Ethernet

Cabling technology

10/100Base-T(X)

Static route

Yes

VLAN support

Yes

Traffic control

Yes

Port forwarding

Yes

Auto MDI/MDI-X

Yes

Policy-based routing

Yes

Mobile network

Mobile network generation

4G standard

LTE

Short Message Service (SMS)

Yes

Management features

Web-based management

Yes

Quality of Service (QoS) support

Yes

Universal Plug and Play (UPnP)

Yes

Wake-on-LAN ready

Yes

Reset button

Yes

WPS push button

Firmware upgradeable

Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports

Fast Ethernet (copper) ports quantity

Power over Ethernet (PoE) ports quantity

Protocols

DMZ support

Yes

Management protocols

FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS

VoIP protocols

H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets

DHCP client

Yes

DHCP server

Yes

Supported network protocols

TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)

Security

Security algorithms

HTTPS

Firewall

Yes

DoS attack prevention

Yes

ARP attack prevention

Yes

ICMP attack prevention

Yes

Access Control List (ACL)

Yes

Packaging content

Manual

Yes

Features

Built-in processor

Yes

Processor frequency

580 MHz

Flash memory

16 MB

Internal memory

128 MB

Operating system installed

RutOS

Certification

CE, UKCA, EAC, UCRF, RCM

Design

Product colour

White

Housing material

Plastic

Rack mounting

Yes

LED indicators

Status

Antenna

Antenna type

Internal

Antennas quantity

Power

Power consumption (typical)

2.5 W

Power consumption (max)

6 W

Power source type

DC, PoE

Power over Ethernet (PoE)

Yes

Operational conditions

Operating temperature (T-T)

-40 - 75 °C

Operating relative humidity (H-H)

10 - 90%

Weight & dimensions

Width

100 mm

Depth

235 mm

Height

49.3 mm

Weight

855 g

Other features

Input voltage

42.5 - 57 V
