Tripp Lite PDUMH32HVNET 7.4kW Single-Phase Switched PDU, LX Interface, 230V Outlets (16-C13), IEC-309 Blue 230V 32A, 3.6m Cord, 2U Rack-Mount, TAA

Tripp Lite PDUMH32HVNET 7.4kW Single-Phase Switched PDU, LX Interface, 230V Outlets (16-C13), IEC-309 Blue 230V 32A, 3.6m Cord, 2U Rack-Mount, TAA

Name: Tripp Lite PDUMH32HVNET 7.4kW Single-Phase Switched PDU, LX Interface, 230V Outlets (16-C13), IEC-309 Blue 230V 32A, 3.6m Cord, 2U Rack-Mount, TAA
Brand: Eaton
SKU: PDUMH32HVNET
Price: 966.22 EUR
Availability: OutOfStock

This Switched PDU offers advanced network control and monitoring with the ability to turn on, turn off, recycle or lock out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. Built-in LX Platform network management interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. Individually switched outlets can be controlled in real time to remotely reboot unresponsive network hardware or be custom programmed for user-defined power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in amps is displayed locally via front panel current meter or remotely via web/network interface to warn of potential overloads before critical IT mains or branch breakers trip.

ON ORDER

SKU: PDUMH32HVNET

Manufacturer: Eaton Eaton

RRP Price €966.22

Specifications

Design

PDU types

Metered

Rack capacity

Mounting

Horizontal

Housing material

Metal

Product colour

Black

Display

LCD

Ports & interfaces

AC outlets quantity

16 AC outlet(s)

Power plug

IEC309

AC outlet types

C13 coupler

Features

LED indicators

Yes

Cable length

3.65 m

Power

Nominal input voltage

230 V

AC input frequency

50 - 60 Hz

Maximum current

32 A

Nominal output voltage

230 V

Certificates

Compliance certificates

RoHS

Certification

IEC 60950-1

Operational conditions

Storage temperature (T-T)

-15 - 50 °C

Operating altitude

0 - 3000 m

Weight & dimensions

Width

445 mm

Depth

317.5 mm

Height

89 mm

Weight

6.21 kg

Packaging data

Package weight

7.44 kg

Package width

429.3 mm

Package depth

500.4 mm

Package height

195.6 mm

Logistics data

Country of origin

Taiwan

Products per master (outer) case

1 pc(s)

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

6.21 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
