StarTech.com PCIe HDMI Video Capture Card - HDMI, VGA, DVI, or Component Video at 1080p60 - TAA

Use this dual-profile internal capture card to record 1080p video at 60 frames per second

This PCIe video capture card lets you record 1080p HD video and 2-channel stereo audio (HDMI/RCA) to your computer system. With multiple video inputs, including HDMI, DVI, VGA and component, this all-in-one capture card can record original content from virtually any device.

You can install the card into any low-profile or full-profile PCIe slot, including fixed workstations such as 2U or 4U rack-mounted servers or media centers. Installing your capture device internally through PCIe ensures a secure and reliable way to capture video.

Seamless picture quality at 60 frames per second

With frame rates up to 60fps (frames per second) and H.264 encoding, this card is perfect for capturing high-definition video for editing, compiling, and archiving. The capture card supports 16:9 and 4:3 aspect ratios and lets you record lossless video at 60fps. This ensures that every frame of content is saved, unlike 30fps capture devices that only capture half the action.

60fps exactly matches the output of most computer video cards, which makes this capture card great for recording the output from your PC, server, or point-of-sale station, when creating software training and tutorial videos.

H.264 encoding for wide device compatibility

The included software encodes captured video in H.264 -- the most widely adopted video compression standard in the world. This ensures your video captures are compatible with most device platforms such as PC, Mac, iOS and Androidâ„¢.

The software not only lets you capture and export videos, but it also lets you take screenshots, schedule recordings and instantly stream your video source over the internet using online services such as Twitch, and others.

This HD capture card can record lossless raw video, which makes it compatible with Microsoft® DirectShow. This means you can record video using your preferred third-party DirectShow software, such as Open Broadcaster Software (OBS).

Flexible input solutions for convenient compatibility

This adapter card features DVI-I signaling and multiple adapters to support many video input types. With multiple A/V input options, you can capture video from a wide variety of sources including HDMI, DVI, VGA, and component. You can also expand the capabilities of this capture card by using A/V adapters to record from other video sources such as SDI, using our SDI to HDMI converter (SDI2HD) (sold separately). Support for a variety of A/V devices and signals is ideal for archiving analog video footage into a digital database.

The capture device also includes easy-to-use software that’s compatible with NTSC and PAL systems - a must-have for professional video archiving applications where source media can change from project to project.

Notes:

This capture device will not record digitally encrypted content.

Computer System Requirements:

Expansion slot: PCI-Express 2

CPU: i5-3330 or higher

RAM: 4GB or higher

Operating system: Microsoft® Windows® 11, 10, 8.1, 8

The StarTech.com Advantage

ON ORDER

SKU: PEXHDCAP60L2

Manufacturer: StarTech.com StarTech.com

RRP Price €400.72

Specifications

Performance

Product colour
Green
Internal
Yes
Host interface
PCIe
Video capture resolution (max)
1920 x 1080 pixels
Certification
CE, FCC, REACH, TAA

Video

Analog signal format system
NTSC, PAL 60, PAL M
Supported video modes
480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Audio

Audio support
Yes

File formats

Video compression formats
H.264, MPEG4

Ports & interfaces

USB port
No
Component video (YPbPr/YCbCr) in
1
DVI-I ports quantity
1

Software

Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

System requirements

Minimum system requirements
CPU: i5-3330 RAM: 4GB

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-5 - 50 °C
Operating relative humidity (H-H)
20 - 80%

Technical details

Compliance certificates
CE, RoHS

Weight & dimensions

Width
69 mm
Depth
141 mm
Height
15 mm
Weight
70 g

Other features

Master (outer) case width
470 mm
Master (outer) case height
470 mm

Packaging data

Package weight
300 g
Package height
38 mm
Package width
207 mm
Package depth
144 mm

Packaging content

Interface adapters included
DVI-I male - HDMI female, DVI-I male - VGA female
Cables included
Component, Composite, S-Video
Full-height bracket
Yes
Quick installation guide
Yes

Logistics data

Products per master (outer) case
72 pc(s)
Master (outer) case length
475 mm
Harmonized System (HS) code
85176990
