Teltonika Industrial router RUT142 WiFi 4, RS232, 2x RJ45 100Mb/s, IP30

The RUT142 is a compact industrial Ethernet router, enhancing security through network isolation for end devices. Equipped with the RS232 serial interface, two Ethernet ports, DIN rail bracket, and an industrial 3-pin connector, it ensures seamless connectivity and easy installation. The router comes with RutOS, Wi-Fi 4, and supports industrial protocols such as Modbus, DLMS, DNP3, and OPC UA, and is compatible with RMS for efficient remote and on-site management.

ON ORDER

SKU: RUT142

Manufacturer: Teltonika Teltonika

RRP Price €65.60

Specifications

WAN connection

Ethernet WAN
Yes
DSL WAN
No
SIM card slot
No
3G/4G USB modem compatibility
No
WAN connection type
RJ-45

Wireless LAN features

Wi-Fi band
Single-band (2.4 GHz)
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)
300 Mbit/s
Wi-Fi standards
802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Ethernet LAN
Yes
Ethernet LAN interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Cabling technology
10/100Base-T(X)
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s, IEEE 802.11v, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Full duplex
Yes
Auto-sensing
Yes
Auto MDI/MDI-X
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
2
USB port
No
USB 2.0 ports quantity
1
RS-232 ports
1

Management features

Web-based management
Yes
Quality of Service (QoS) support
Yes

Security

Security algorithms
AES-CCMP, EAP-TLS, OWE, SSH, TKIP, WPA-PSK, WPA2-EAP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE

Protocols

DHCP client
Yes
DHCP server
Yes

Design

Product colour
Black
Housing material
Aluminium
International Protection (IP) code
IP30
Indication light
Yes
LED indicators
LAN, Power, WAN
Product type
Industrial router

Certificates

Certification
CE/RED, UKCA, CB, RCM, FCC, IC, EAC, UCRF, WEEE

Antenna

Antenna design
External
Antenna connector type
RP-SMA
Antennas quantity
1

Features

Built-in processor
Yes
Processor manufacturer
MediaTek
Processor architecture
MIPS 24Kc
Processor frequency
580 MHz
Internal memory
128 MB
Internal memory type
DDR2
Flash memory
16 MB

Power

Power source type
DC, PoE

Operational conditions

Operating temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%

Weight & dimensions

Width
113.1 mm
Depth
68.6 mm
Height
25 mm
Weight
149.2 g

Accessories

License
