TP-Link JetStream 52-Port Gigabit L2+ Managed Switch with 48-Port PoE+

JetStream 52-Port Gigabit L2+ Managed Switch with 48-Port PoE+

3 IN STOCK

SKU: TL-SG3452P

Manufacturer: TP-Link TP-Link

RRP Price €679.76

Specifications

Management features

Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
Cloud-managed
Yes
ARP inspection
Yes
System event log
Yes
MIB support
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
4
Console port
RJ-45/micro-USB
Power connector
AC-in jack

Network

Networking standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x
10G support
No
Port mirroring
Yes
IP routing
Yes
Policy-based routing
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Head-of-line (HOL) blocking
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Active link detection
Yes
VLAN support
Yes
Virtual LAN features
MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs
4000

Data transmission

Switching capacity
104 Gbit/s
Forwarding rate
77.4 Mpps
MAC address table
16000 entries
Store-and-forward
Yes
Static route
Yes
Number of static routes
48
Jumbo frames support
Yes
Jumbo frames
9000
Packet buffer memory
12 MB

Security

DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
SSH/SSL support
Yes
Loop protection
Yes
BPDU filtering/protection
Yes
Authentication
MAC-based authentication, Port-based authentication
Password protection
Yes

Multicast features

Multicast support
Yes

Protocols

Management protocols
SNMPv1/v2c/v3, SNTP
GARP VLAN Registration Protocol (GVRP)
Yes

Design

Rack mounting
Yes
Form factor
1U
Product colour
Black
Reset button
Yes
LED indicators
Yes
Number of fans
3 fan(s)

Power

Power source
AC
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (max)
485.4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
48
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
384 W

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
1656.19 BTU/h

Weight & dimensions

Width
440 mm
Depth
330 mm
Height
44 mm

Packaging content

Cables included
AC
Quick start guide
Yes
Manual
Yes

Packaging data

Package type
Box
Package width
440 mm
Package depth
528 mm
Package height
100 mm
Package weight
6.77 kg

Logistics data

Harmonized System (HS) code
85176990

Accessories
