Extreme networks 5420M-24W-4YE network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)

5420 Series
Universal Edge Switch Platform
The 5420 Series is a family of high-performance, feature-rich, stackable edge switches designed for the next-generation digital enterprise. Available in 24 and 48-port models, the 5420 features both gigabit and multi-gigabit (1/2.5G) versions with up to 90W PoE enabling it to be deployed across a range of edge and wiring-closet environments. As a universal hardware platform, the 5420 also offers a user-selectable choice of Extreme’s flagship switch operating systems for a uniquely flexible platform.
The 5420 Series consists of 5420M and 5420F families to address a variety of end-user needs and price points. 5420M models offer fieldreplaceable power supplies and fans as well as four 1/10/25Gb builtin uplink ports, while 5420F models offer fixed power supply (with support for a second field-replaceable power supply), fixed fans, and four 1/10Gb built-in uplink ports. All models provide 30/60/90W PoE capabilities making them an ideal wired back end for wireless APs or in support of NextGen powered Ethernet devices, such as digital signage, pan-tilt-zoom cameras, smart lighting, or point-of-sale terminals.

ON ORDER

SKU: 5420M-24W-4YE

Manufacturer: Extreme networks Extreme networks

RRP Price €6,398.76

Specifications

Management features

Quality of Service (QoS) support
Yes
Cloud-managed
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Fiber optic connector
SFP28
Console port
RJ-45
SFP28 ports quantity
4
USB 2.0 ports quantity
2

Network

Networking standards
IEEE 802.3bt
10G support
Yes
Full duplex
Yes
Half duplex
Yes

Data transmission

Switching capacity
328 Gbit/s
Forwarding rate
244 Mpps

Security

Security algorithms
128-bit AES, 256-bit AES

Design

Rack mounting
Yes
Stackable
Yes
LED indicators
Yes

Performance

Noise level
33 dB

Power

Power source
PoE
Power consumption (typical)
43 W
Power consumption (max)
1601 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) power per port
90 W
Total Power over Ethernet (PoE) budget
1440 W

Weight & dimensions

Width
442 mm
Depth
330.2 mm
Height
43.2 mm
Weight
4.4 kg

Accessories

License
