Cisco Catalyst C9500-24Q-A network switch Managed L2/L3 1U Grey

The Cisco® Catalyst® 9500 Series switches are the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Cisco Catalyst 9500 Series is Cisco’s lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The switches come with a 4-core x86, 2.4-GHz CPU, 16-GB DDR4 memory, and 16-GB internal storage.

The Cisco Catalyst 9500 Series is the industry’s first purpose-built 40 and 100 Gigabit Ethernet line of switches targeted for the enterprise campus. These switches deliver unmatched table scale (MAC/route/ACL) and buffering for enterprise applications. The Cisco Catalyst 9500 Series includes nonblocking 40 and 100 Gigabit Ethernet Quad Small Form-Factor Pluggable (QSFP+, QSFP28) and 1, 10 and 25 Gigabit Ethernet Small Form-Factor Pluggable Plus (SFP/SFP+/SFP28) switches with granular port densities that fit diverse campus needs. The switches support advanced routing and infrastructure services (such as Multiprotocol Label Switching [MPLS] Layer 2 and Layer 3 VPNs, Multicast VPN [MVPN], and Network Address Translation [NAT]); Cisco Software-Defined Access capabilities (such as a host tracking database, cross-domain connectivity, and VPN Routing and Forwarding [VRF]-aware Locator/ID Separation Protocol [LISP]); and network system virtualization with Cisco StackWise® virtual technology that are critical for their placement in the campus core. The Cisco Catalyst 9500 Series also supports foundational high-availability capabilities such as patching, Graceful Insertion and Removal (GIR), Cisco Nonstop Forwarding with Stateful Switchover (NSF/SSO), redundant platinum-rated power supplies, and fans.

ON ORDER

SKU: C9500-24Q-A

Manufacturer: Cisco Cisco

RRP Price €14,945.08

Specifications

Management features

Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Weighted random early detection (WRED)
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports type
No
QSFP+ module slots quantity
24
Fiber optic connector
QSFP+
Console port
RJ-45

Network

Networking standards
IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Yes
Zero Touch Provisioning (ZTP)
Yes
Full duplex
Yes
Flow control support
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
Multiprotocol Label Switching (MPLS)
Yes
VLAN support
Yes
Number of VLANs
4000

Optical fiber

Switching optical modules type
40 Gigabit Ethernet

Data transmission

Switching capacity
960 Gbit/s
Throughput
1440 Mpps
MAC address table
64000 entries
Jumbo frames support
Yes
Jumbo frames
9198

Security

DHCP features
DHCP snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
256-bit AES

Multicast features

Multicast support
Yes

Protocols

Virtual Router Redundancy Protocol (VRRP)
Yes
Routing protocols
BGP, EIGRP, HSRP

Design

Rack mounting
Yes
Form factor
1U
Product colour
Grey
LED indicators
Yes
Safety
UL 60950 - 1, CAN/CSA - C22.2 No. 60950 - 1, EN 60950 - 1, IEC 60950 - 1, AS/NZS 60950 - 1, GB4943

Performance

Built-in processor
Yes
Processor frequency
2400 MHz
Memory type
DRAM
Internal memory
16000 MB
Flash memory
16000 MB
Firmware upgradeable
Yes
Plug and Play
Yes
Mean time between failures (MTBF)
230770 h

Power

AC input voltage
115 - 230 V
AC input frequency
50 - 60 Hz
Output voltage
12 V
Power consumption (typical)
850 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 65 °C
Operating relative humidity (H-H)
5 - 90%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 1800 m
Heat dissipation
2901 BTU/h

Weight & dimensions

Width
445 mm
Depth
567 mm
Height
44 mm
Weight
11.7 kg

Certificates

Certification
47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A EN50082-1 EN61000-6-1 EN55024 CISPR24 EN300386 KN 24 KN 61000-4 series

Logistics data

Harmonized System (HS) code
85176990
