Eaton EMIH28 power distribution unit (PDU) 8 AC outlet(s) 1U Black

ON ORDER

SKU: EMIH28

Manufacturer: Eaton Eaton

RRP Price €646.81

Specifications

Design

PDU types
Metered
Type
Single-phase
Form factor
Rackmount
Rack mounting
Yes
Rack capacity
1U
Mounting
Horizontal
Product colour
Black
Cable colour
Black
Display
LCD

Ports & interfaces

AC outlets quantity
8 AC outlet(s)
Power plug
C20 coupler
AC outlet types
C13 coupler
Ethernet LAN (RJ-45) ports
1
Input connection type
IEC-320-C20
Output connections
8 x C13

Features

Cable length
3 m

Management features

Monitoring
Current
Supported network protocols
HTTP, HTTPS, SSL, Telnet, FTP, SNMP, SMTP, DNS, DHCP, LDAP, RADIUS
Management protocols
SNMP, Telnet
Firmware upgradeable
Yes
Firmware upgradeable via
Network, USB

Power

Nominal input voltage
230 V
AC input frequency
50 Hz
Maximum current
16 A
Nominal output voltage
230 V
Maximum input current per phase
16 A
Maximum power
3700 W

Certificates

Compliance certificates
RoHS
Certification
CB, CE, EN 60950-1:2006/A11:2009/A1:2010/A12:2011 Safety - Part 1: General Requirements, IEC 60950-1(ed.2), IEC 60950-1(ed.2);am1 EN 55022:2010, EN 61000-6-2:2005 Part 6-2, EN 50581 : 2012, REACH, WEEE, PEP, ISO 9001:2008, ISO 14001:2004

Operational conditions

Operating temperature (T-T)
0 - 60 °C

Weight & dimensions

Width
203 mm
Depth
482.6 mm
Height
44.5 mm
Weight
2.6 kg

Packaging content

Cables included
LAN (RJ-45)
Rack mount kit
Yes

Packaging data

Package weight
3.8 kg

Accessories

License
