TP-Link MC111CS network media converter 100 Mbit/s Single-mode Black

The MC111CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media or vice versa. Adopting WDM technology, MC111CS takes only one fiber cable to transmit and receive data, which will half cable cost for you. Designed with IEEE 802.3u 100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on transferring data and at 1310nm on receiving data. So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data. Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS. Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers(12.5 miles).

37 IN STOCK

SKU: MC111CS

Manufacturer: TP-Link TP-Link

RRP Price €33.52

Specifications

Network

Maximum data transfer rate
100 Mbit/s
Networking standards
IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates
10,100 Mbit/s
Auto MDI/MDI-X
Yes
Duplex system
Full, Half
Cable types supported
Cat3, Cat4, Cat5, Cat5e

Performance

Maximum transfer distance
20000 m
Wavelength-division multiplexing (WDM)
Yes
Fiber mode structure
Single-mode

Features

Internal
No
LED indicators
Yes
Product colour
Black

Ports & interfaces

Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Fiber ports quantity
1
Fiber optic connector
SC

Power

Power consumption (max)
2.49 W

Weight & dimensions

Width
95 mm
Depth
73 mm
Height
27 mm

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%

Packaging content

Manual
Yes

Certificates

Compliance certificates
RoHS

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
