Cisco SG250X-48 Managed L2/L3 Gigabit Ethernet (10/100/1000) 1U Black

In today's hyper-connected world, reliable access to network resources is critical to all businesses. However, you also need to invest wisely to stay competitive, knowing how to separate the essential from the extraneous and get the most value for your dollar. For investment in network infrastructure, building a solid foundation for your business is essential, but it doesn’t mean you need the most advanced feature set on the market.

For businesses requiring high performance, advanced security, and rich manageability from the network, fully managed switches are an excellent choice. However, they also typically come with high price tags. Smart switches provide the right level of network features and capabilities for growing businesses at a lower price, so you’ll have more dollars to put toward other areas of your business.

With Cisco 250 Series Smart Switches, you can achieve business-class network performance and security without paying for advanced network features that you will not use. When you need a reliable solution to share online resources and connect computers, phones, and wireless access points, but low cost is a top priority, Cisco 250 Series Smart Switches provide the ideal solution.

ON ORDER

SKU: SG250X-48-K9-EU

Manufacturer: Cisco Cisco

RRP Price €2,654.76

Specifications

Management features

Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
System event log
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
48
SFP+ module slots quantity
2
USB 2.0 ports quantity
1

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Yes
Copper ethernet cabling technology
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
Port mirroring
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Head-of-line (HOL) blocking
Yes
VLAN support
Yes
Virtual LAN features
Voice VLAN, Tagged VLAN, Port-based VLAN
Number of VLANs
255

Data transmission

Switching capacity
176 Gbit/s
Forwarding rate
130.94 Mpps
MAC address table
8000 entries
Number of queues
8
Jumbo frames support
Yes
Jumbo frames
9000
Packet buffer memory
24 MB

Security

DHCP features
DHCP server, DHCP relay
Access Control List (ACL)
Yes
Access Control List (ACL) rules
512
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, HTTPS, SSH, SSL/TLS
SSH/SSL support
Yes
Loop protection
Yes
DoS attack prevention
Yes
Queue scheduling algorithms
Weighted Round Robin (WRR)

Protocols

GARP VLAN Registration Protocol (GVRP)
Yes
IPv4 & IPv6 features
Dual stack IPv4/IPv6

Design

Rack mounting
Yes
Form factor
1U
Product colour
Black
Reset button
Yes
LED indicators
Yes
Number of fans
2 fan(s)

Performance

Built-in processor
Yes
Processor frequency
800 MHz
Internal memory
512 MB
Flash memory
256 MB
Noise level
49.3 dB
Firmware upgradeable
Yes
Plug and Play
Yes
Mean time between failures (MTBF)
68585 h

Power

Power supply included
Yes
AC input voltage
110 - 220 V
AC input frequency
50 - 60 Hz
Power consumption (max)
46 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Heat dissipation
156.96 BTU/h

Weight & dimensions

Width
440 mm
Depth
257 mm
Height
44 mm
Weight
3 kg

Packaging content

Quick start guide
Yes
Rack mount kit
Yes

Certificates

Certification
UL, FCC, CSA

Accessories

License
