Ubiquiti UniFi US-16-XG network switch Managed L2 10G Ethernet (100/1000/10000) 1U Grey

Ubiquiti UniFi US-16-XG network switch Managed L2 10G Ethernet (100/1000/10000) 1U Grey

Name: Ubiquiti UniFi US-16-XG network switch Managed L2 10G Ethernet (100/1000/10000) 1U Grey
Brand: Ubiquiti
SKU: US-16-XG
Price: 759.12 EUR
Availability: OutOfStock

10G Aggregation Switch for Enterprise Networks
Build and expand your network with Ubiquiti Networks® UniFi® Switch 16 XG, part of the UniFi Enterprise System. The
US‑16‑XG is a fully managed, 16-port, 10G fiber switch that enhances network capacity by providing high-bandwidth
aggregation connectivity to multiple switches in your network.
The US‑16‑XG offers an extensive suite of advanced Layer-2 switching features and protocols.

Switching Performance
The US‑16‑XG offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
The total non-blocking throughput is up to 160 Gbps.

10G High-Capacity Links
The US‑16‑XG offers maximum performance and low latency as an aggregation switch.
For fiber connectivity, it features 12 SFP+ ports. For copper connectivity, the US‑16‑XG offers four RJ45 ports that
support 10GBASE-T, the standard for 10 Gbps connections using Cat6 (or higher) cabling and RJ45 connectors.

The US‑16‑XG connects to the following:
- Multiple UniFi Switches and a 1G/10G router via SFP+ ports
- VM, Server, NAS, or other network devices via 1G/10G RJ45 ports

UniFi Controller
Designed for convenient management, the UniFi Controller software allows admins to configure and monitor the UniFi Switch and other UniFi devices using a graphical user interface. You can download it from www.ubnt.com at no cost.

Multi-Site Management
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Switch Configuration
You can access any managed UniFi Switch through the UniFi Controller to configure a variety of features:
- Operation mode (switching, mirroring, or aggregate) per port
- Network/VLAN configuration
- Jumbo frame and flow control services
- Network settings
- Storm control setting per port
- Spanning tree configuration
- 802.1x control and RADIUS VLAN
- Debug terminal option for command-line interface

Switch Port Status
You can also view status information for each port:
- Connection speed and duplex mode
- TX/RX data rates
- Network/VLAN setting

Dashboard
The Dashboard tab provides a visual representation of your network’s status. Basic information is provided for each network segment.

Device Configuration
The Devices screen displays the UniFi devices discovered by the UniFi Controller. You can access each managed device for device details and configuration.

ON ORDER

SKU: US-16-XG

Manufacturer: Ubiquiti

RRP Price €759.12

Specifications

Management features

Switch type

Managed

Switch layer

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

10G Ethernet (100/1000/10000)

SFP+ module slots quantity

Console port

RJ-45

Power connector

DC-in jack

Network

Networking standards

IEEE 802.1x

10G support

Yes

Cable types supported

Cat6

Port mirroring

Yes

Full duplex

Yes

Link aggregation

Yes

Broadcast storm control

Yes

Spanning tree protocol

Yes

VLAN support

Yes

Data transmission

Switching capacity

320 Gbit/s

Forwarding rate

238.1 Mpps

Jumbo frames support

Yes

Security

Security algorithms

802.1x RADIUS

Design

Rack mounting

Yes

Form factor

Product colour

Grey

Housing material

Steel

Reset button

Yes

LED indicators

Yes

Number of fans

2 fan(s)

Power

Power supply included

Yes

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Input voltage

25 - 16 V

Power consumption (typical)

36 W

Power consumption (max)

56 W

Operational conditions

Operating temperature (T-T)

-5 - 40 °C

Operating relative humidity (H-H)

5 - 95%

Weight & dimensions

Width

443 mm

Depth

221 mm

Height

43 mm

Weight

2.62 kg

Packaging content

Cables included

Quick start guide

Yes

Packaging data

Mounting brackets included

Yes

Package type

Box

Screws included

Yes

Certificates

Certification

CE, FCC, IC, ETSI300-019-1.4

Logistics data

Harmonized System (HS) code

85176990

Description

Manufacturer

Ubiquiti

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

2.62 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
