Cisco WS-C3650-48FQM-L network switch Managed L2 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black

The Cisco® Catalyst® 3650 Series is the next generation of enterprise-class standalone and stackable access-layer switches that provide the foundation for full convergence between wired and wireless on a single platform. The 3650 Series is built on the advanced Cisco StackWise®-160, and takes advantage of the new Cisco Unified Access™ Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. The 3650 Series switches support full IEEE 802.3at Power over Ethernet P.lus (PoE+), Cisco Universal Power over Ethernet (Cisco UPOE®) on the Cisco Catalyst 3650 Series multigigabit switches, and offer modular and field-replaceable redundant fans and power supplies. The 3650 Series swiwww.cisco.com/c/en/us/products/collateral/switches/catalyst-3650-series-switches/datasheet-c78-729449.htmltches also come in a 12-inch lower depth form factor so that you can deploy them in tight wiring closets in remote branches and offices where depth of the switch is a concern. In addition, the 3650 multigigabit switches support current and next-generation wireless speeds and standards (including 802.11ac Wave 2) on existing cabling infrastructure. The 3650 Series switches help increase wireless productivity and reduce TCO.

ON ORDER

SKU: WS-C3650-48FQM-L

Manufacturer: Cisco Cisco

RRP Price €25,124.02

Specifications

Management features

Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
Traffic classification
Yes
Traffic shaping
Yes
ARP inspection
Yes
MIB support
Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
SFP+ module slots quantity
4
Fiber optic connector
SFP+
Power connector
DC-in jack

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3x, IEEE 802.3z
10G support
Yes
Cable types supported
Cat5, Cat5e, Cat6, Cat6a
Full duplex
Yes
IP routing
Yes
Flow control support
Yes
Link aggregation
Yes
Rate limiting
Yes
Auto MDI/MDI-X
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Virtual LAN features
Stacked VLAN, Private VLAN, Port-based VLAN

Data transmission

Switching capacity
392 Gbit/s
MAC address table
32000 entries
Jumbo frames support
Yes
Jumbo frames
9198

Security

DHCP features
DHCP server, DHCP client
Access Control List (ACL)
Yes
IGMP snooping
Yes
MAC address filtering
Yes
SSH/SSL support
Yes
BPDU filtering/protection
Yes

Multicast features

Multicast support
Yes
Multicast MAC address table
24000 entries

Design

Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Black
LED indicators
Yes
Wall mountable
Yes

Performance

Flash memory
4096 MB
Mean time between failures (MTBF)
272260 h

Power

Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
5 - 12 A
Power consumption (max)
975 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
48
Total Power over Ethernet (PoE) budget
775 W

Operational conditions

Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3000 m

Weight & dimensions

Width
445 mm
Depth
296 mm
Height
44 mm
Weight
5.74 kg

Packaging content

User guide
Yes
Manual
Yes

Packaging data

AC adapter included
Yes

Logistics data

Harmonized System (HS) code
85176990
