Zyxel XMG1930-30HP Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black

Zyxel XMG1930-30HP Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black

Name: Zyxel XMG1930-30HP Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
Brand: Zyxel
SKU: XMG1930-30HP-ZZ0101F
Price: 1551.55 EUR
Availability: InStock

The XMG1930 series is a family of Multi-Gigabit L2 Smart Managed switches including 2 models, with and without PoE options.
On top of its high-density twenty-four 2.5G ports that serve as a top performance access switch to upgrade from standard gigabit network, the switches also offer four 10G Multi-Gigabit ports to expand network connection to WiFi 6/6E AP or 10G servers along with two additional 10G fiber ports for extensibility and resilience. The PoE model XMG1930-30HP supports both PoE+ and PoE++ with a large power budget of 700 W offering great flexibility to deploy WiFi 6/6E and WiFi 7 wireless access points; while the non-PoE model XMG1930-30 is ideal for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user.

2 IN STOCK

SKU: XMG1930-30HP-ZZ0101F

Manufacturer: Zyxel Zyxel

RRP Price €1,551.55

Specifications

Management features

Switch type

Managed

Switch layer

Quality of Service (QoS) support

Yes

Web-based management

Yes

Cloud-managed

Yes

Configuring Location Settings (CLI)

Yes

MIB support

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

2.5G Ethernet (100/1000/2500)

10G Ethernet (copper) ports quantity

Installed SFP+ modules quantity

Fiber optic connector

SFP+

Power connector

AC-in jack

Network

Networking standards

IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z

10G support

Yes

Policy-based routing

Yes

Flow control support

Yes

Broadcast storm control

Yes

Rate limiting

Yes

Spanning tree protocol

Yes

Ethernet LAN data rates

10,100,1000,2500,10000 Mbit/s

VLAN support

Yes

Number of VLANs

4000

Data transmission

Switching capacity

240 Gbit/s

Forwarding rate

178.5 Mpps

MAC address table

16000 entries

Static route

Yes

Jumbo frames support

Yes

Jumbo frames

12000

Security

DHCP features

DHCP client, DHCPv6 relay

Access Control List (ACL)

Yes

IGMP snooping

Yes

MAC address filtering

Yes

SSH/SSL support

Yes

Loop protection

Yes

Multicast features

Multicast support

Yes

Protocols

GARP VLAN Registration Protocol (GVRP)

Yes

Design

Rack mounting

Yes

Form factor

Product colour

Black

Reset button

Yes

LED indicators

Yes

Performance

Mean time between failures (MTBF)

587922.31 h

Power

Power source

Power supply included

Yes

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power consumption (max)

864.1 W

Power over Ethernet (PoE)

Yes

Power over Ethernet (PoE) ports quantity

Power over Ethernet plus (PoE+) ports quantity

Total Power over Ethernet (PoE) budget

700 W

Operational conditions

Operating temperature (T-T)

-20 - 50 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

5 - 95%

Storage relative humidity (H-H)

5 - 95%

Heat dissipation

864.1 BTU/h

Weight & dimensions

Width

441 mm

Depth

330 mm

Height

44 mm

Weight

4.85 kg

Packaging content

Cables included

Rack mount kit

Yes

Description

Manufacturer

Zyxel

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

Weight

4.85 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
