NETGEAR XS512EM Managed L2 10G Ethernet (100/1000/10000) 1U Blue, Grey

NETGEAR XS512EM Managed L2 10G Ethernet (100/1000/10000) 1U Blue, Grey

Name: NETGEAR XS512EM Managed L2 10G Ethernet (100/1000/10000) 1U Blue, Grey
Brand: Netgear
SKU: XS512EM-100EUS
Price: 1412.24 EUR
Availability: InStock

Unlock your Network Potential with 10-Gigabit/Multi-Gigabit 5-Speed Networking Switches
Revolutionary 5-speed 10-Gigabit/Multi-Gigabit technology built in the NETGEAR multi-speed switches allows your devices to speed past the Gigabit barrier.

With the growth of virtualization, flash Storage, 4K videos , video streaming and IP surveillance, SMB networks need to extend beyond 1 Gigabit barrier. The 10-Gigabit/Multi-Gigabit Smart Managed Plus series from NETGEAR presents the right solution for this requirement; delivering unprecedented 10-Gigabit/Multi-Gigabit bandwith at an affordable cost.

Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS512EM and XS724EM gives the exact speed required, no downgrade. Also, the new NETGEAR Multi-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6/Cat6A wiring, therefore reducing wiring costs and hassle

13 IN STOCK

SKU: XS512EM-100EUS

Manufacturer: Netgear Netgear

RRP Price €1,412.24

Specifications

Management features

Switch type

Managed

Switch layer

Quality of Service (QoS) support

Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

10G Ethernet (100/1000/10000)

SFP+ module slots quantity

Power connector

DC-in jack

Network

Networking standards

IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

10G support

Yes

Broadcast storm control

Yes

VLAN support

Yes

Virtual LAN features

Port-based VLAN

Number of VLANs

Data transmission

Switching capacity

240 Gbit/s

MAC address table

32000 entries

Store-and-forward

Yes

Jumbo frames support

Yes

Jumbo frames

9000

Packet buffer memory

3 MB

Security

DHCP features

DHCP client

IGMP snooping

Yes

MAC address filtering

Yes

Design

Rack mounting

Yes

Form factor

Product colour

Blue, Grey

LED indicators

Yes

Number of fans

2 fan(s)

Performance

Mean time between failures (MTBF)

1113477 h

Power

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Input current

2 A

Power over Ethernet (PoE)

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

0 - 90%

Storage relative humidity (H-H)

0 - 95%

Heat dissipation

261.38 BTU/h

Weight & dimensions

Width

328 mm

Depth

204 mm

Height

43 mm

Weight

2.51 kg

Sustainability

Sustainability certificates

ENERGY STAR

Certificates

Certification

47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN55032:2012+AC:2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2013, VCCI-CISPR32:2016, CNS 13438, IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015 CNS14336-1

Logistics data

Harmonized System (HS) code

85176990

Description

Manufacturer

Netgear

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

Weight

2.51 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
