Extreme networks X460-G2-48X-10GE4-BASE Managed L2/L3 1U Purple

X460-G2 series – the scalable advanced aggregation and edge switch with the revolutionary ExtremeXOS modular operating system.

The X460-G2 series is based on Extreme Networks revolutionary ExtremeXOS, a highly resilient OS that provides continuous uptime, manageability, and operational efficiency. Each switch offers the same high-performance, non-blocking hardware technology, in the Extreme Networks tradition of simplifying network deployments through the use of common hardware and software throughout the network.

The X460-G2 switches are effective campus-edge switches with IEEE 802.3at PoE-plus and can also serve as aggregation switches for traditional enterprise networks. The X460-G2 series is also an option for DSLAM or CMTS aggregation, or for active Ethernet access.

The X460-G2 can also be used as a top-of-rack switch for many data center environments with features such as high-density Gigabit Ethernet for concentrated data center environments; XNVâ„¢ (ExtremeXOS Network Virtualization) for centralized network-based Virtual Machine (VM) inventory, VM location history, and VM provisioning; Direct Attachâ„¢ to offload VM switching from servers, thereby improving performance; high-capacity Layer 2/Layer 3 scalability for highly virtualized data centers; and intra-rack and cross-rack stacking with industry-leading flexibility.

ON ORDER

SKU: 16706

Manufacturer: Extreme networks Extreme networks

RRP Price €12,750.63

Specifications

Management features

Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes

Ports & interfaces

Gigabit Ethernet (copper) ports quantity
1
Fiber ports quantity
52
Fiber optic connector
SFP, SFP+
Console port
RJ-45
USB 2.0 ports quantity
1

Network

Networking standards
IEEE 1588, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3z
10G support
Yes
Full duplex
Yes
Rate limiting
Yes
VLAN support
Yes
Number of VLANs
4092

Data transmission

Switching capacity
336 Gbit/s
Throughput
250 Mpps
Number of trunks
128
Jumbo frames support
Yes
Packet buffer memory
4 MB

Security

Access Control List (ACL)
Yes
DoS attack prevention
Yes

Design

Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Purple
LED indicators
Yes

Performance

Built-in processor
Yes
Processor frequency
1000 MHz
Memory type
DDR3-SDRAM
Internal memory
1024 MB
Flash memory
4000 MB

Power

AC input voltage
85 - 264 V
AC input frequency
47/63 Hz
Power consumption (typical)
59 W
Power consumption (max)
143 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 95%
Storage relative humidity (H-H)
10 - 95%
Operating altitude
0 - 3000 m

Weight & dimensions

Width
441 mm
Depth
432 mm
Height
44 mm
Weight
6.4 kg
