Fortinet Layer 2/3 FortiGate switch controller compatible switch with 24 x GE RJ45 ports, 4 x 10 GE SFP+ uplinks

ON ORDER

SKU: FS-424E

Manufacturer: Fortinet Fortinet

RRP Price €1,586.91

Specifications

Management features

Switch type
Managed

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Fiber ports quantity
4
Fiber optic connector
SFP+
Console port
RJ-45

Network

10G support
Yes
Link aggregation
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Number of VLANs
4000

Data transmission

Switching capacity
128 Gbit/s
Forwarding rate
204 Mpps
MAC address table
16000 entries
Packet buffer memory
2 MB

Security

Access Control List (ACL)
Yes

Design

Rack mounting
Yes
Form factor
1U
Product colour
White

Performance

Memory type
DDR4-SDRAM
Internal memory
1000 MB
Flash memory
256 MB
Mean time between failures (MTBF)
87600 h

Power

Power supply included
Yes
Redundant power supply (RPS) support
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
22.3 W
Power consumption (max)
23.6 W

Operational conditions

Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Heat dissipation
76.04 BTU/h

Weight & dimensions

Width
440 mm
Depth
260 mm
Height
44 mm
Weight
3.1 kg

Certificates

Certification
FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Accessories

License
