Trendnet TU-S9E interface cards/adapter RS-232

TRENDnet’s 1-Port Serial to IP Ethernet Converter, model TU-S9E, allows you to easily and remotely manage an RS-232 serial device within your local network. With a flat and compact size, the RS-232 to Ethernet converter is ideal for cabinet installations where space can be limited. The rugged housing design is suited for most installation environments, including harsh and industrial environments. Setup is easy and the included software offers simple configuration for customizing the RS-232 to Ethernet converter to seamlessly fit your network application.

RS232 to Ethernet
This converter allows you to connect and configure an RS-232 device over an IP network for remote access and management.

Simple Management
You can use the included software or a web browser to manage the converter and the RS-232 device.

Rugged Design
This converter has a sturdy metal housing that can withstand harsh and industrial environments.

Compact
This converter has a flat and compact size that is ideal for cabinet installations where space is limited.

Mount
This converter comes with wall mounting brackets for easy installation.

Software Utility
This converter includes a software utility that helps you to access and manage the RS-232 device remotely.


Simple Management
Use included software or web browser to manage the converter.


Rugged Design
Equipped with a sturdy metal housing design.




RS232
Connect and configure an RS-232 device over an IP network for remote access


Compact
The flat and compact size of the serial to Ethernet adapter is ideal for cabinet installations where space can be very limited


Housing Design
Equipped with a sturdy metal housing design that can withstand harsh and industrial environments


Mount
Includes wall mounting brackets for the serial to Ethernet converter


Software Utility
Included RS232 to Ethernet converter software utility allows you to easily access and manage an RS-232 device remotely

ON ORDER

SKU: TU-S9E

Manufacturer: Trendnet Trendnet

RRP Price €63.92

Specifications

Ports & interfaces

Host interface
RJ-45
Host interface gender
Female
Output interface
RS-232
Serial ports quantity
1
Serial interface type
RS-232

Design

Internal
No
Product colour
Black
Cooling type
Passive
Certification
CE, FCC

Features

Connector 1 gender
Female
Connector 2 gender
Female
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Data transfer rate (max)
0.1 Gbit/s

Power

Output voltage
5 V
Output current
1 A
Power supply input voltage
100 - 240 V
Power supply input frequency
50/60 Hz
External power adapter
Yes
USB powered
No

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 95%

System requirements

Windows operating systems supported
Yes

Weight & dimensions

Width
62 mm
Depth
42 mm
Height
23 mm
Weight
102 g

Packaging data

Quantity per pack
1 pc(s)
Quick installation guide
Yes

Accessories

License
