Cisco Catalyst 2960CX-8TC-L Network Switch, 8 Gigabit Ethernet Ports, two 1 G SFP and two 1 G Copper Uplinks, Enhanced Limited Lifetime Warranty (WS-C2960CX-8TC-L)

The Cisco Catalyst 2960CX-8TC-L Network Switch is ideal for high-speed data connectivity and Wi-Fi backhaul in places where space is at a premium. Featuring a compact design and quiet, fanless operation, this managed switch can come out of the server room and be placed closer to users, meaning shorter cable runs and greater flexibility for your network deployment.

ON ORDER

SKU: WS-C2960CX-8TC-L

Manufacturer: Cisco Cisco

RRP Price €1,967.36

Specifications

Management features

Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
2
Combo SFP ports quantity
2
Console port
RJ-45
Power connector
DC-in jack

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
10G support
No
Copper ethernet cabling technology
10GBASE-T, 100BASE-T, 1000BASE-T
Full duplex
Yes
Link aggregation
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
VLAN support
Yes

Data transmission

Switching capacity
12 Gbit/s
Forwarding rate
17.9 Mpps
Jumbo frames support
Yes
Jumbo frames
9198

Security

DHCP features
DHCP server, DHCP snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, SSH
SSH/SSL support
Yes
Authentication
MAC-based authentication, Web-based authentication
Authentication type
IEEE 802.1x

Multicast features

Multicast support
Yes

Protocols

Management protocols
Telnet, RIP, SNMP, NTP, TACACS+, RMON, HTTP, RADIUS
Data link protocols
UDP, TFTP, IP, TCP, FTP
Supported network protocols
ICMP, ARP, BOOTP, OSPF, DHCP

Design

Rack mounting
No
Product colour
White
LED indicators
Yes
Market segment
Business

Performance

Memory type
DRAM
Internal memory
512 MB
Flash memory
128 MB
Mean time between failures (MTBF)
756260 h

Power

AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
0.5 A
Power consumption (typical)
18.8 W
Power plug type
Type C

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Other features

Packaging content
WS-C2960CX-8TC-L Switch, Accessory Kit, 1 printed document

Operational conditions

Operating temperature (T-T)
-5 - 45 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 4000 m
Heat dissipation
170.6 BTU/h

Weight & dimensions

Width
269 mm
Depth
213 mm
Height
44.4 mm
Weight
1.72 kg

Packaging data

Package width
327.7 mm
Package depth
349.2 mm
Package height
160.3 mm
Package weight
1.72 kg

Technical details

Products per shipping (inner) case
1 pc(s)

Certificates

Certification
FCC, CE, CFR 47, EN 55022, EN 55024, AS/NZS, CISPR22:2004, EN55022, VCCI, KCC, ANATEL, CCC, GOST

Logistics data

Quantity per pack
1 pc(s)
Country of origin
China
Harmonized System (HS) code
85176990
Products per master (outer) case
1 pc(s)
