Tripp Lite U336-MMF-1G-LC USB 3.0 Multimode Fiber Optic Transceiver Ethernet Adapter, 10/100/1000 Mbps, 1310nm, 550m, LC

Connects Your Laptop or PC to a Wired Fiber Network without an Internet Card Installed
This USB to LC fiber optic Ethernet adapter allows you to instantly connect your computer, laptop, tablet or other USB-compatible device to a wired 10/100/1000 Mbps fiber optic network, even if your device has no NIC (Network Interface Controller) installed. The adapter offers access to a Gigabit Ethernet network when Wi-Fi is unavailable or when a wired connection offers faster speeds. It transmits data up to 550 meters (1804 feet) from your fiber network using a wavelength of 1310nm.

Hot-Swappable for Installation Without Network Interruption
This USB 3.0 Multimode Fiber Optic Transceiver Ethernet adapter is fully hot-swappable, so you can install it without a potentially costly network shutdown or device reboot. Just connect the built-in USB cable to your device’s USB port (which also powers the adapter), and connect the LC duplex port to a high-speed network switch, router or hub using existing or newly run multimode fiber cable (such as N820-Series, sold separately).

Delivers Full Gigabit Ethernet Performance with Audio and Video Streaming
The compact USB to Ethernet adapter supports full 1 Gbps network speeds and USB 3.0 speeds, allowing you to transfer data efficiently and stream audio and video. The direct fiber connection minimizes the risk of data leaks and electromagnetic interference (EMI). A blue LED indicates successful Ethernet connection and data transfer. The adapter works with Windows and Microsoft Server operating systems.

ON ORDER

SKU: U336-MMF-1G-LC

Manufacturer: Eaton Eaton

RRP Price €265.68

Specifications

Ports & interfaces

Connectivity technology
Wired
Host interface
USB
Interface
Fiber
Fiber ports quantity
1
Fiber optic connector
LC
USB version
3.2 Gen 1 (3.1 Gen 1)

Network

Maximum data transfer rate
1000 Mbit/s
Maximum operating distance
550 m

Design

Component for
PC/Laptop
Product colour
White
Internal
No
LED indicators
Yes
Country of origin
China
Certification
CE, FCC, REACH

Power

USB powered
Yes

Operational conditions

Operating temperature (T-T)
0 - 55 °C
Storage temperature (T-T)
0 - 60 °C
Operating relative humidity (H-H)
5 - 90%
Storage relative humidity (H-H)
5 - 90%

Weight & dimensions

Weight
50 g

Packaging data

Package width
111 mm
Package depth
39.1 mm
Package height
157 mm
Package weight
130 g

Technical details

Compliance certificates
RoHS

Logistics data

Master (outer) case GTIN (EAN/UPC)
10037332225990
Harmonized System (HS) code
85176990
Master (outer) case width
172 mm
Master (outer) case length
245.1 mm
Master (outer) case height
220 mm
Master (outer) case gross weight
1.33 kg
Products per master (outer) case
10 pc(s)

Other features

Housing material
ABS, Polyvinyl chloride (PVC)
Minimum operating temperature
0 °C
Maximum operating temperature
55 °C
Quick start guide
Yes

Accessories
