StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter

Name: StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter
Brand: StarTech.com
SKU: 25SAT22MSAT
Price: 66.10 EUR
Availability: OutOfStock

Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.

Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.

You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.

Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.

The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.

The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs

ON ORDER

SKU: 25SAT22MSAT

Manufacturer: StarTech.com

RRP Price €66.10

Specifications

Ports & interfaces

Host interface

SATA

Output interface

mSATA

SATA revision

3.0

Port multiplier

Yes

Design

Internal

Yes

Product colour

Black, Green

Mean time between failures (MTBF)

5101299 h

Hot-swap

Certification

CE, FCC

Features

Chipset

JMicron JMS562

Data transfer rate (max)

6 Gbit/s

RAID levels

0, 1, BIG, JBOD

Plug and Play

Yes

Operational conditions

Operating temperature (T-T)

-40 - 85 °C

System requirements

Windows operating systems supported

Yes

Mac operating systems supported

Yes

Linux operating systems supported

Yes

Technical details

Compliance certificates

RoHS

Weight & dimensions

Width

70 mm

Depth

97 mm

Height

7 mm

Weight

39 g

Packaging data

Mounting brackets included

Yes

Quick installation guide

Yes

Package width

174 mm

Package depth

145 mm

Package height

32 mm

Package weight

107 g

Logistics data

Harmonized System (HS) code

84733020

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.039 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
