Eaton 9SX uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W 9 AC outlet(s)

2 IN STOCK

SKU: 9SX3000I

Manufacturer: Eaton Eaton

RRP Price €2,414.03

Specifications

Features

UPS topology
Double-conversion (Online)
Output power capacity
3 kVA
Output power
2700 W
Waveform
Pure sine
Input operation voltage (min)
200 V
Input operation voltage (max)
276 V
Input frequency
40/70 Hz
Output operation voltage (min)
200 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Number of input phases
1
Number of output phases
1
Power factor
0.9
ECO mode
No
Noise level
45 dB

Ports & interfaces

AC outlet types
C13 coupler, C19 coupler
Power plug
C20 coupler
AC outlets quantity
9 AC outlet(s)
USB port
Yes
USB 2.0 ports quantity
1
Serial interface
Yes
Serial interface type
RS-232
RS-232 ports
1

Battery

Battery technology
Sealed Lead Acid (VRLA)
Typical backup time at half load
15.5 min
Hot-swap battery
Yes
Automatic battery test
Yes

Design

Form factor
Tower
Product colour
Black
Display type
LCD

Operational conditions

Operating temperature (T-T)
0 - 40 °C

Certificates

Certification
IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC

Safety regulation & standards

Safety
IEC/EN 62040-1, UL 1778, CSA 22.2

Weight & dimensions

Width
214 mm
Depth
412 mm
Height
346 mm
Weight
33.4 kg

Packaging data

Management card included
No
Bundled software
Intelligent Power Software suite

Logistics data

Harmonized System (HS) code
85078000

Other features

Input connection type
IEC C20
Nominal output voltage
230 V
Nominal input voltage
230 V

Accessories

License
