APC Netshelter Rack Automatic Transfer Switch, 1U, 10A, 230V, C14 IN, 12 C13 OUT, 50/60Hz

APC Netshelter Rack Automatic Transfer Switch, 1U, 10A, 230V, C14 IN, 12 C13 OUT, 50/60Hz

Name: APC Netshelter Rack Automatic Transfer Switch, 1U, 10A, 230V, C14 IN, 12 C13 OUT, 50/60Hz
Brand: APC
SKU: AP4421A
Price: 1192.69 EUR
Availability: InStock

APC NetShelter Rack Automatic Transfer Switch (ATS) AP4421A is the Fifth-Generation range of high availability switches offering greater control of your IT equipment from Cloud to Edge. With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. AP4421A is single phase 1U Rack ATS with 10A rated current, 230V rated voltage and 2000VA load capacity. It comes with 2 IEC C14 inlet and 12 IEC C13 outlet sockets. This has been upgraded with APC NMC3 and various technical advancements for network port sharing, environmental monitoring and enhanced security. It has 2-years of standard warranty and 5-years of extended warranty for peace of mind and use for years to come. Users can access and configure Rack ATS through secure Web UI, SNMP, CLI and are fully compatible with EcoStruxure IT.

70 IN STOCK

SKU: AP4421A

Manufacturer: APC APC

RRP Price €1,192.69

Specifications

Power

Input operation voltage (min)

207 V

Input operation voltage (max)

253 V

AC input frequency

50 - 60 Hz

Input current

10 A

Output current

10 A

Design

Form factor

Rackmount

Rack capacity

Product colour

Black

Display

LCD

Ports & interfaces

AC outlets quantity

12 AC outlet(s)

AC outlet types

C13 coupler

Operational conditions

Operating temperature (T-T)

-5 - 45 °C

Storage temperature (T-T)

-25 - 65 °C

Operating relative humidity (H-H)

5 - 95%

Technical details

Total carbon footprint (kg of CO2e)

450.72

Weight & dimensions

Width

432 mm

Depth

236 mm

Height

44 mm

Weight

3.93 kg

Description

Manufacturer

APC

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

Weight

3.93 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
