Eaton EATS16 power distribution unit (PDU) 9 AC outlet(s) 1U Black

Power Source Transfer Switch

Seamless power transfer
Eaton ATS are designed to provide power supply redundancy for single connection equipment. With ATS, power from two independent sources can be supplied to IT equipment, which have only one input power supply.

Redundancy
Only advanced servers are equipped with a dual electrical power supply. The majority of network devices and entry-level servershave a single connection with only one electrical power input.
With the Eaton ATS, critical equipment can be connected to a redundant power supply.
Both sources (primary and secondary) are connected in a straightforward manner to the ATS in the base of the rack.
The Eaton ATS then controls the redundancy of this electrical power supply. If the primary source fails, transfer to the secondary source is automatic and instantaneous.

Simple and cost-effective
Considering the advanced design of the Eaton ATS, these are highly competitive in price compared with the ‘dual power supply’ options available from suppliers of networking equipment. 1U high, the unit can be installed easily within the rack. Metering and basic configuration capabilities are possible through ATS 16’s LCD.

Network connectivity
The ATS 16 Netpack and ATS 30 provide network connectivity.
This allows users to access, configure and manage units from
remote locations.

2 IN STOCK

SKU: EATS16

Manufacturer: Eaton Eaton

RRP Price €928.67

Specifications

Design

PDU types
Basic
Form factor
Rackmount
Rack mounting
Yes
Rack capacity
1U
Mounting
Horizontal
Product colour
Black
Display
LCD

Ports & interfaces

AC outlets quantity
9 AC outlet(s)
Power plug
C20 coupler
AC outlet types
C13 coupler, C19 coupler
Master AC outlets quantity
9

Features

LED indicators
Yes

Power

Nominal input voltage
230 V
AC input frequency
50 - 60 Hz
Maximum current
16 A
Maximum input current per phase
16 A

Certificates

Certification
IEC/EN 62310-1, IEC/EN 60950-1, IEC/EN 62310-2, CE

Weight & dimensions

Width
430 mm
Depth
250 mm
Height
43 mm
Weight
3.3 kg

Packaging content

Rack mount kit
Yes

Accessories

License
