StarTech.com 120x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector

Name: StarTech.com 120x25mm Computer Case Fan with PWM – Pulse Width Modulation Connector
Brand: StarTech.com
SKU: FAN12025PWM
Price: 12.32 EUR
Availability: OutOfStock

Add a Variable Speed, PWM-controlled Cooling Fan to your Computer Case

The FAN12025PWM 120mm PWM Case Fan adds an efficient air cooling solution to computer cases or other enclosures to help ensure optimal performance from internal components.

With Pulse Width Modulation (PWM) technology, the fan speed can be dynamically controlled by the motherboard, so the fan runs at a speed that suits the operating conditions - lowering power consumption and fan noise when the system is idle, and delivering maximum cooling under full load conditions.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- PWM control enables the fan to be controlled by the motherboard according to current system requirements, ensuring optimal system performance
- Ever Lubricate bearing design increases reliability and lifespan over fans with a traditional sleeve bearing design
- Backed by a StarTech.com 2-year warranty and free lifetime technical support

ON ORDER

SKU: FAN12025PWM

Manufacturer: StarTech.com

RRP Price €12.32

Specifications

Performance

Suitable location

Computer case

Type

Fan

Fan diameter

12 cm

Noise level (high speed)

39 dB

Mean time between failures (MTBF)

40000 h

Operating temperature (T-T)

-10 - 70 °C

Design

Product colour

Black

Material

Plastic

Power

Voltage

12 V

Rated current

0.32 A

Weight & dimensions

Weight

128 g

Package width

145 mm

Package depth

201 mm

Package height

32 mm

Package weight

188 g

Other features

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

0 - 65%

Fan performance

78.41 cfm

Dimensions (WxDxH)

120 x 120 x 25 mm

Connector(s)

1 - Molex Fan (4 pin; PWM)

Rotational speed

220 RPM

Logistics data

Harmonized System (HS) code

84733080

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.128 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download

Accessories

No Accessories Found!

License

No License Found!
