StarTech.com 10/100 Multi Mode Fiber Ethernet Media Converter SC 2 km

StarTech.com 10/100 Multi Mode Fiber Ethernet Media Converter SC 2 km

Name: StarTech.com 10/100 Multi Mode Fiber Ethernet Media Converter SC 2 km
Brand: StarTech.com
SKU: MCM110SC2EU
Price: 71.20 EUR
Availability: InStock

The MCM110SC2EU 10/100 Multi Mode Fiber Ethernet Media Converter (SC, 2 km) creates a cost-effective Ethernet-fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals, to extend an Ethernet network connection over an SC-terminated multimode fiber backbone.

The converter supports a maximum multimode fiber optic cable distance of 2 kilometers (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using SC-terminated multimode fiber, while delivering solid network performance and scalability.

This versatile Ethernet to Fiber converter is compatible with most 3COM™, Cisco™, Lucent™ and Nortel™ networks and fully complies with applicable IEEE 802.3 standards.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage
- Improve network scalability by increasing the distances between network points by up to 2km (Multi-mode)
- Compact, lightweight enclosure is easily mounted or placed into any location with little to no configuration needed
- Provides increased bandwidth and high data throughput by eliminating network bottlenecks and congestion

7 IN STOCK

SKU: MCM110SC2EU

Manufacturer: StarTech.com

RRP Price €71.20

Specifications

Network

Maximum data transfer rate

100 Mbit/s

Converter input interface

100BASE-FX, 100Base-TX, 10Base-T

Networking standards

IEEE 802.1Q, IEEE 802.3, IEEE 802.3u

Ethernet LAN data rates

10,100 Mbit/s

Jumbo frames support

Yes

Jumbo frames

9000

Flow control support

Yes

Auto MDI/MDI-X

Yes

Auto-negotiation

Yes

Duplex system

Full, Half

Performance

Maximum transfer distance

2000 m

Wavelength

1310 nm

Wavelength-division multiplexing (WDM)

Fiber mode structure

Multi-mode

Mean time between failures (MTBF)

65000 h

Features

Internal

LED indicators

Activity, Link, Power

Product colour

Black

Housing material

Plastic

Ports & interfaces

Connectivity technology

Wired

Ethernet LAN (RJ-45) ports

Fiber ports quantity

Fiber optic connector

DC-in jack

Yes

Power

Input voltage

230 V

Output voltage

12 V

Output current

0.2 A

Power over Ethernet (PoE)

Power plug type

Type M

Weight & dimensions

Width

75 mm

Depth

95 mm

Height

20 mm

Weight

90.5 g

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-10 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Packaging content

AC adapter included

Yes

Manual

Yes

Packaging data

Package width

145 mm

Package depth

175 mm

Package height

65 mm

Package weight

300 g

Certificates

Compliance certificates

RoHS

Certification

CE, FCC

Logistics data

Harmonized System (HS) code

85176990

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

0.0905 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
