D-Link Wireless AC1200 Wave2 Dual Band Outdoor PoE Access Point

The WiFi4EU ready DAP-3666 Wireless AC1200 Wave 2 Dual-Band Outdoor PoE Access Point is a versatile, high power outdoor access point designed with harsh weather resistant features making it an ideal solution for creating outdoor wireless hotspot networks. Utilising the cutting-edge speed of 802.11ac Wave 2, it delivers maximum combined wireless signal rates of up to 1200Mbps and supports MU-MIMO technology that allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. It is Passpoint® certified by Wi-Fi Alliance and complies with Hotspot 2.0, making the process of devices finding and getting access to the known network seamless.
For centralised network management, administrators can use D-Link’s free Nuclias Connect software or Nuclias Connect Hub (DNH-100) to configure and manage multiple access points. In addition to streamlining the management process, Nuclias Connect provides network administrators with the means to verify and conduct regular maintenance checks remotely, eliminating the need to send personnel out to physically verify proper operation.

5 IN STOCK

SKU: DAP-3666

Manufacturer: D-Link D-Link

RRP Price €260.36

Specifications

Features

2.4 GHz
Yes
5 GHz
Yes
6 GHz
No
Maximum data transfer rate
1200 Mbit/s
Maximum data transfer rate (2.4 GHz)
300 Mbit/s
Maximum data transfer rate (5 GHz)
867 Mbit/s
Ethernet LAN data rates
10,100,1000 Mbit/s
Frequency band
2.4, 5 GHz
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Cabling technology
10/100/1000Base-T(X)
Transmitting power
26 dBmW
Mean time between failures (MTBF)
30000 h

Security

Security algorithms
64-bit WEP, SSID, 128-bit WEP
Number of SSID supported
16

Ports & interfaces

Ethernet LAN (RJ-45) ports
2
WAN connection
Ethernet (RJ-45)
DC-in jack
Yes

Power

Power over Ethernet (PoE)
Yes
DC voltage range
48 V
Power consumption (max)
10.5 W

Design

Placement
Pole
Product colour
White
Cable lock slot
Yes
LED indicators
Power

Antenna

Antenna type
Internal
Antenna features
Integrated antenna
Antennas quantity
2
Antenna gain level (max)
6 dBi

Certificates

Certification
FCC, IC, CE, UL, Wi-Fi Certified, Wi-Fi Certified Passpoint

Weight & dimensions

Width
277 mm
Depth
50 mm
Height
240 mm

Packaging content

Quantity per pack
1 pc(s)

Operational conditions

Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
-30 - 60 °C
Storage temperature (T-T)
-30 - 65 °C
Storage relative humidity (H-H)
5 - 95%

Logistics data

Harmonized System (HS) code
85176990
