Tripp Lite SR42BMDEXPNDNR3 42U SmartRack 4-Post Mid-Depth Open Frame Rack, Expansion Version - no sides, doors or roof

The SR42BMDEXPNDNR3 offers 36-inch (927-millimeter) depth opposed to the standard 42 inchs (1050 millimeters).

The SR42BMDEXPNDNR3 houses 3,500 pounds (1588 kilograms) of standard 19-inch rack equipment in 42U. It is an expansion model that comes without sides, doors or roof. The front and rear pairs of vertical rails have square mounting holes that are adjustable in quarter-inch increments from four to 28.75 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference and supports tool-less button-mount 0U installation of up to four compatible PDUs and cable managers.

All components of the SR42BMDEXPNDNR3 are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground.

To simplify deployment, the SR42BMDEXPNDNR3 comes with preinstalled three-inch casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: The casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances.

ON ORDER

SKU: SR42BMDEXPNDNR3

Manufacturer: Eaton Eaton

RRP Price €1,454.93

Specifications

Features

Rack capacity
42U
Type
Freestanding rack
Maximum weight capacity
1360 kg
Product colour
Black
Certification
UL60950, RoHS, CE

Weight & dimensions

Width
600.2 mm
Depth
914.4 mm
Height
2019.3 mm
Weight
42.6 kg

Packaging data

Package width
660.4 mm
Package depth
960.1 mm
Package height
2159 mm
Package weight
59 kg

Logistics data

Country of origin
China
Harmonized System (HS) code
8517.79.0000
Master (outer) case width
660.4 mm
Master (outer) case length
960.1 mm
Master (outer) case height
2159 mm
Master (outer) case gross weight
59 kg
Products per master (outer) case
1 pc(s)

Other features

Package dimensions (WxDxH)
66.04 x 96 x 215.9 mm
