Tripp Lite SRWF12U38 SmartRack 12U Low-Profile Vertical-Mount Wall-Mount Small Server Rack Enclosure

Name: Tripp Lite SRWF12U38 SmartRack 12U Low-Profile Vertical-Mount Wall-Mount Small Server Rack Enclosure
Brand: Eaton
SKU: SRWF12U38
Price: 701.90 EUR
Availability: OutOfStock

The SRWF12U38 SmartRack® 12U Low-Profile Vertical-Mount Server-Depth Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices, two-post racks and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 400 lbs (181.4 kgs).

Because the low-profile cabinet mounts vertically, it extends only 16 inches from the wall while housing equipment up to 35 inches deep, including 1U servers, UPS systems, battery packs and switches. In addition to 8U of rack space in the primary mounting area, it also includes a 4U mounting space at the top of the enclosure for patch panels.

The top cover and front panel are removable to allow expedient access to equipment. The cover also locks securely with the included keys to help prevent damage, tampering or theft. The vented cabinet allows air to flow freely and keep equipment cool. Convenient top, bottom and side ports allow easy cable routing.

The SRWF12U38's modular design allows you to disassemble the cabinet in minutes for wall-mounting with user-supplied hardware. Mounting holes are spaced 16 inches apart to accommodate standard wall studs. Equipment installation is easy with threaded mounting holes that support 12-24 mounting in two-post racks.

ON ORDER

SKU: SRWF12U38

Manufacturer: Eaton Eaton

RRP Price €701.90

Specifications

Features

Rack capacity

12U

Type

Freestanding rack

Maximum weight capacity

181437 kg

Product colour

Black

Key lock

Yes

Weight & dimensions

Width

500 mm

Depth

410.4 mm

Height

965.2 mm

Weight

30.3 kg

Mounting depth (max)

88.9 cm

Packaging data

Manual

Yes

Package width

570 mm

Package depth

1089.9 mm

Package height

479.8 mm

Package weight

37.6 kg

Logistics data

Country of origin

China

Harmonized System (HS) code

8517.79.0000

Master (outer) case width

570 mm

Master (outer) case length

1089.9 mm

Master (outer) case height

479.8 mm

Master (outer) case gross weight

37.6 kg

Products per master (outer) case

1 pc(s)

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

30.3 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
